Product Name: 3300 XL 25 mm Proximity Probe
Brand Name: Bently Nevada
Model Number: 330851-06-000-070-10-00-05
Place of Origin: United States
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Tag
| Bently Nevada 3300 XL 25 mm Proximity Probe | 3300 XL Series Probe |
| 330851-06-000-070-10-00-05 | Non-contact Measurement System |
| Proximity Probe | PEEK Tip Probe |
| Vibration Monitoring Sensor | Stainless Steel Probe Housing |
| Shaft Displacement Probe | M39x1.5 Thread Probe |
| Eddy Current Sensor | Critical Equipment Monitoring |
| Steam Turbine Monitoring | Turbine Vibration Sensor |
| Generator Condition Monitoring | Industrial Automation Sensor |
| Rotating Machinery Protection | High Temperature Proximity Probe |
| Industrial High-Temperature Sensor | Machinery Condition Monitoring System |
The Bently Nevada 330851-06-000-070-10-00-05 is a 3300 XL 25 mm proximity probe designed for high-precision vibration and shaft displacement measurement in critical rotating machinery such as steam turbines and generators.
It features a PEEK probe tip and AISI 304 stainless steel housing, ensuring excellent thermal stability, mechanical strength, and long service life in harsh industrial environments. The probe supports a vertical adjustment range of 25.4 mm, allowing flexible installation and alignment.
With a wide operating temperature range of -35°C to +200°C and short-term resistance up to +250°C, the 330851-06-000-070-10-00-05 is ideal for demanding high-temperature applications. It is engineered for reliable performance in critical asset monitoring and protection systems.
|
Sales |
|
|
|
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Winnie |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Bently Nevada 330851-06-000-070-10-00-05 3300 XL 25 mm Proximity Probe |
| Manufacturer | Bently Nevada |
| Product Type | 3300 XL 25 mm Proximity Probe |
| Part Number | 330851-06-000-070-10-00-05 |
| Dimensions | 110x5x5cm |
| Weight | 0.66kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Probe dc Resistance | 6.2 ± 0.5 Ω |
| Probe Tip Material | Polyetheretherketone (PEEK) |
| Probe Case Material | AISI 304 stainless steel (SST) |
| Probe adapter vertical adjustment | 25.4 mm (1.00 in) total travel |
| Probe and Extension Cable Armor (optional) | Flexible AISI 302 SST with PFA outer jacket. |
| Operating and Storage Temperature | -35°C to +200°C (-31°F to +392°F) |
| Short Term Operating and Storage Temperature | +250 °C (482 °F) max for less than 24 hours |
| Probe Case Type Option | M39x1.5 thread |
| Unthreaded Length Option | 00 mm |
| Overall Case Length Option | 70 mm |
| Total Length Option | 1.0 metre (3.3 feet) |
| Armor Option | No Armor |
| Agency Approval Option | Multiple Approvals |
1. What type of probe tip is used in 330851-06-000-070-10-00-05?
The 330851-06-000-070-10-00-05 uses a PEEK (Polyetheretherketone) probe tip for high-temperature durability and stability.
2. What is the cable length of 330851-06-000-070-10-00-05?
The 330851-06-000-070-10-00-05 comes with a 1.0 meter (3.3 feet) cable.
3. What is the thread type of 330851-06-000-070-10-00-05?
The 330851-06-000-070-10-00-05 uses an M39 × 1.5 threaded probe case design.
4. Does 330851-06-000-070-10-00-05 include armor protection?
No, the standard 330851-06-000-070-10-00-05 does not include armor, but an optional flexible stainless steel armor is available.
5. What is the vertical adjustment feature of 330851-06-000-070-10-00-05?
The 330851-06-000-070-10-00-05 supports 25.4 mm (1.00 in) vertical adjustment for flexible installation alignment.
6. What industries use 330851-06-000-070-10-00-05?
The 330851-06-000-070-10-00-05 is commonly used in power generation, especially steam turbines and generator monitoring systems.
