Product Name: 3300 XL 8 mm Proximity Probes
Brand Name: Bently Nevada
Model Number: 330104-08-14-10-02-05
Place of Origin: United States
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
overview
| Product Name | 3300 XL 8 mm Proximity Probes |
| Brand Name | Bently Nevada |
| Model Number | 330104-08-14-10-02-05 |
| Place of Origin | USA |
| Warranty | 12 months |
| Payment Methods | T/T |
| Shipment | DHL/UPS/EMS/Fedex... |
The Bently Nevada 330104-08-14-10-02-05 3300 XL 8 mm Proximity Probe is a high-performance eddy current transducer designed for accurate shaft vibration and position monitoring in industrial machinery. Manufactured by Bently Nevada, it is part of the 3300 XL 8 mm Transducer System, which includes the probe, extension cable, and Proximitor sensor.
Built with a PPS probe tip and AISI 303/304 stainless steel housing, the probe offers excellent durability and measurement stability in demanding environments. It features a 75 Ω triaxial FEP-insulated cable and a ClickLoc miniature coaxial connector for reliable, low-noise signal transmission. With CSA, ATEX, and IECEx certifications, it is suitable for use in hazardous and explosive environments.
The Bently Nevada 330104-08-14-10-02-05 3300 XL 8 mm Proximity Probe performs precise non-contact measurement of shaft vibration and position, enabling continuous monitoring of rotating machinery. It detects mechanical issues such as imbalance, misalignment, and shaft instability through accurate radial vibration measurement.
It also measures axial and radial displacement, providing essential feedback for machinery protection and control systems. As part of a complete transducer system, it generates an output voltage proportional to the distance between the probe tip and the conductive target surface, allowing both static position and dynamic vibration analysis.
Additionally, the probe supports Keyphasor reference and speed measurement applications, making it widely used in fluid-film bearing machines and other critical equipment.
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
| Product Name | Bently Nevada 330104-08-14-10-02-05 3300 XL 8 mm Proximity Probes |
| Manufacturer | Bently Nevada |
| Product Type | 3300 XL 8 mm Proximity Probes |
| Part Number | 330104-08-14-10-02-05 |
| Dimensions | 111.5x2x2cm |
| Weight | 0.14kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Condition | New & Original in Factory Packing |
| Unthreaded Length Option | 80 mm |
| Overall Case Length Option | 140 mm |
| Total Length Option | 1.0 meter (3.3 feet) |
| Connector and Cable-Type Option | Miniature coaxial ClickLocconnector standard cable |
| Agency Approval Option | CSA, ATEX, IECEx Approvals |
| Output Resistance | 50 Ω |
| Nominal Probe DC Resistance | 7.45 ± 0.50 Ω |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 stainless steel (SST) |
| Probe Cable | 75Ω triaxial, fluoroethylene propylene (FEP) insulated |
| Armor (optional on both) | Flexible AISI 302 or 304 SST with FEP outer jacket |
The Bently Nevada 330104-08-14-10-02-05 3300 XL 8 mm Proximity Probe is constructed with a PPS probe tip for thermal stability and an AISI 303/304 stainless steel case for corrosion resistance. It utilizes a 75 Ω triaxial FEP-insulated cable and 50 Ω output resistance, ensuring high signal integrity and compatibility with industrial monitoring systems.
Its nominal DC resistance of 7.45 ± 0.50 Ω provides stable electrical characteristics for accurate measurement. The probe offers flexible installation with an 80 mm unthreaded length, 140 mm case length, and 1.0 m total cable length, while the ClickLoc connector ensures quick and secure connections.
Optional armored cabling (AISI 302/304 SST with FEP jacket) enhances durability in harsh environments. The probe is also certified for hazardous areas with CSA, ATEX, and IECEx approvals, ensuring safe operation in high-risk industrial applications.
The Bently Nevada 330104-08-14-10-02-05 3300 XL 8 mm Proximity Probe delivers high accuracy and stable performance through its advanced eddy current sensing technology. It provides consistent and repeatable measurements with minimal signal loss due to its triaxial cable design and secure ClickLoc connection.
Its robust construction ensures reliable operation under extreme temperatures, mechanical stress, and industrial contamination. The probe supports predictive maintenance strategies by delivering real-time, high-quality monitoring data, helping reduce downtime and maintenance costs. Additionally, its efficient electrical design ensures stable operation within standard industrial power ranges, contributing to overall system reliability and performance.
Q1: What technology does the Bently Nevada 330104-08-14-10-02-05 3300 XL 8 mm Proximity Probe use?
A: The 330104-08-14-10-02-05 3300 XL 8 mm Proximity Probe uses eddy current (non-contact) sensing technology.
Q2: Can the Bently Nevada 330104-08-14-10-02-05 be used in hazardous environments?
A: Yes, the 330104-08-14-10-02-05 is certified with CSA, ATEX, and IECEx approvals for hazardous environments.
Q3: What measurements can the 330104-08-14-10-02-05 provide?
A: The 330104-08-14-10-02-05 Probe provides vibration, displacement, position, and speed (Keyphasor) measurements.
Q4: What ensures signal accuracy in the 330104-08-14-10-02-05 Proximity Probe?
A: The Bently Nevada 330104-08-14-10-02-05 ensures accuracy through its triaxial cable design, stable electrical characteristics, and high-quality materials.
Q5: What are the installation options for the 330104-08-14-10-02-05 Probe?
A: The 330104-08-14-10-02-05 offers flexible installation with multiple length options and a secure ClickLoc connector.
