Product Name: 3300 XL 8 mm Proximity Probe
Brand Name: Bently Nevada
Model Number: 330103-00-21-10-11-CN
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | Bently Nevada 330103-00-21-10-11-CN 3300 XL 8 mm Proximity Probe |
| Manufacturer | Bently Nevada |
| Product Type | 3300 XL 8 mm Proximity Probe |
| Part Number | 330103-00-21-10-11-CN |
| Weight | 0.14kg |
| Estimated shipping dimensions | 1.8x1.5x121cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Nominal Probe DC Resistance | 7.59 ± 0.50 Ω |
| Minimum unthreaded length | 0 mm |
| Overall Case Length Option | 210 mm |
| Total Length Option | 1.0 meter (3.3 feet) |
| Connector and Cable-Type Option | Miniature coaxial ClickLoc connector with connector protector, FluidLoc cable |
| Probe Case Material | AISI 303 or 304 stainless steel (SST). |
| Probe Tip Material | Polyphenylene sulfide (PPS). |
The Bently Nevada 330103-00-21-10-11-CN 3300 XL 8 mm Proximity Probe is a high-precision non-contact eddy current sensor designed for shaft vibration, position, and speed measurements in rotating machinery. As a key component of the 3300 XL 8 mm Proximity Transducer System, the probe detects the distance between its sensing tip and a conductive target surface, converting mechanical displacement into an electrical signal for continuous condition monitoring and machinery protection. This model features an M10 × 1 threaded probe body, a 210 mm case length, and a 1.0 m FluidLoc cable with a miniature coaxial ClickLoc connector for secure and reliable installation.
Constructed with an AISI 303/304 stainless steel housing and a durable Polyphenylene Sulfide (PPS) probe tip, the 330103-00-21-10-11-CN is engineered to withstand demanding industrial environments while maintaining measurement accuracy and long-term stability. Fully compatible with 3300 XL extension cables and Proximitor sensors, the probe supports seamless integration into machinery monitoring systems and complies with the performance requirements of API 670 for critical rotating equipment applications.
The 330103-00-21-10-11-CN functions as the primary sensing element within the 3300 XL 8 mm Proximity Transducer System. Using eddy current technology, it measures the distance between the probe tip and a conductive shaft or target surface without physical contact. Variations in this distance are converted into a proportional voltage signal, enabling highly accurate monitoring of shaft vibration, axial position, eccentricity, and other critical machine parameters.
When connected to a compatible 3300 XL extension cable and Proximitor sensor, the probe provides continuous real-time data for machinery protection and condition-based maintenance programs. The system can detect abnormal vibration levels, shaft movement, misalignment, imbalance, and other developing faults, allowing operators to take corrective action before equipment damage or unplanned downtime occurs.
The Bently Nevada 330103-00-21-10-11-CN is designed for use within the Bently Nevada 3300 XL 8 mm Proximity Transducer System and is compatible with:
Its combination of precision measurement, rugged construction, system interchangeability, and industry-standard compatibility makes the 330103-00-21-10-11-CN an ideal solution for critical machinery monitoring, vibration analysis, and equipment protection in industrial environments.
