Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330103-02-12-05-02-CN
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330103-02-12-05-02-CN |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Description |
|
Model |
330103-02-12-05-02-CN |
|
System Type |
3300 XL 8 mm Eddy Current Proximity System |
|
Thread Type |
M10 x 1 metric thread |
|
Probe Diameter |
8 mm standard probe body |
|
Cable Type |
75Ω triaxial shielded cable |
|
Connector Type |
ClickLoc coaxial connector system |
|
Measurement Range |
Up to 2 mm linear range |
|
Output Type |
Analog voltage proportional to distance |
|
Operating Temperature |
-52°C to +177°C (probe dependent) |
|
System Weight |
0.08kg |
|
Probe Cable Weight |
323 g/m |
|
Extension Cable Weight |
34 g/m |
|
Dimension |
68x1.8x1.5cm |
The 330103-02-12-05-02-CN is part of the high-performance 3300 XL 8 mm proximity probe series developed by Bently Nevada. It is engineered for precise vibration and position measurement in rotating machinery, delivering stable and accurate eddy current sensing performance.
Integrated within the 3300 XL transducer system, this probe works alongside a Proximitor sensor and extension cable to provide reliable non-contact monitoring of shaft movement. It supports both static and dynamic measurement in industrial environments such as turbines, compressors, and motors, ensuring compliance with API 670 standards.
With rugged M10 x 1 threading, interchangeable components, and enhanced EMI/RFI resistance, the 330103-02-12-05-02-CN offers long-term stability, simplified installation, and dependable operation even under harsh industrial conditions.
Q1: What is the main function of the 330103-02-12-05-02-CN probe?
A1: It measures shaft vibration and position using eddy current technology for machinery protection.
Q2: Is this probe compatible with other 3300 XL components?
A2: Yes, it is fully interchangeable with 3300 XL probes, cables, and Proximitor sensors.
Q3: What industries commonly use this probe?
A3: It is widely used in power plants, petrochemical facilities, steel mills, and manufacturing lines.
Q4: What connector type does it use?
A4: It uses the ClickLoc gold-plated coaxial connector for secure and stable connections.
Q5: Can it operate in harsh environments?
A5: Yes, it is designed for high EMI, vibration, and wide temperature industrial conditions.
| Number | Describe |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual |
| 175751 | 3300 XL Multi-Purpose Stainless Steel Housing 12"x12"x6", supports up to 8 Proximitor Sensors (DIN mount) or 6 (panel mount), ATEX Zone 0/1 certified |
| 176467 | 3300 XL Multi-Purpose Stainless Steel Housing 12"x8"x6", supports up to 4 Proximitor Sensors, DIN or panel mount, ATEX Zone 0/1 certified |
| 330181 | 3300 XL Multi-Purpose Stainless Steel Housing 13"x9.5"x7", supports up to 8 sensors (DIN) or 6 (panel), hazardous area approvals, ATEX Zone 0/1, North American Division 1/2 certified |
| 02120015 | Bulk field wire 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, length customizable |
| 138492-01 | Replacement panel-mount mounting pad for 3300 XL systems |
| 138493-01 | Replacement DIN-mount mounting pad for 3300 XL systems |
| 148722-01 | 3300 XL test plug with 3-pin adapter and banana plugs for Proximitor sensor testing without removing field wiring |
| 04310310 | 3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread, 4 screws required per sensor |
| 03200006 | Silicone self-fusing tape roll (9.1 m) for connector protection and environmental insulation |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, includes tools and protectors |
| 136536-01 | Connector protector adapter for compatibility with pre-1998 installation tools |
| 40180-02 | Connector protectors pack (10 pairs) for 3300 XL 8 mm probes and extension cables |
| 03839410 | 75Ω triaxial male connector protector for environmental sealing of probe cable connections |
