Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330103-05-12-10-01-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330103-05-12-10-01-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Specification |
|
Model |
330103-05-12-10-01-00 |
|
Series |
3300 XL 8 mm Proximity Probe |
|
Thread Type |
M10 x 1 metric thread |
|
System Type |
Eddy current non-contact transducer |
|
Total Cable Length |
0.5 m – 9.0 m options |
|
Output Signal |
Analog voltage proportional displacement |
|
Operating Temp |
-52°C to +177°C |
|
Storage Temp |
-52°C to +177°C |
|
Cable Type |
75Ω triaxial shielded cable |
|
Connector Type |
ClickLoc coaxial connector |
|
Material |
Stainless steel probe body |
|
Dimension |
2x1.5x121cm |
|
Weight |
0.1kg |
|
Installation Type |
Panel / DIN rail compatible system |
The330103-05-12-10-01-00belongs to the Bently Nevada 3300 XL 8 mm proximity probe family, designed for accurate non-contact measurement of shaft vibration and position in rotating machinery. It operates as part of a complete eddy current transducer system, including probe, extension cable, and Proximitor Sensor, delivering stable voltage output proportional to target displacement.
The3300 XL 8 mm probe systemis engineered for high reliability in demanding industrial environments. Its robust M10 x 1 threaded design ensures secure installation, while advanced signal stability and EMI resistance support consistent monitoring performance in critical rotating assets.
Widely applied in turbines, compressors, and heavy-duty process equipment, the330103-05-12-10-01-00supports API 670-compliant machinery protection systems, enabling predictive maintenance and continuous condition monitoring across industrial operations.
Q1: What is the main function of the 330103-05-12-10-01-00 probe?
A1: It is used for non-contact measurement of shaft vibration and position in rotating machinery.
Q2: Is this probe compatible with the 3300 XL system?
A2: Yes, it is fully compatible with 3300 XL Proximitor Sensors and extension cables.
Q3: Can it operate in harsh industrial environments?
A3: Yes, it is designed for high temperature, vibration, and EMI-heavy environments.
Q4: Does it support industrial standard compliance?
A4: Yes, it supports API 670-based monitoring system requirements.
Q5: Is calibration required when replacing the probe?
A5: No, components are interchangeable without bench calibration.
| Number | Description |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual |
| 175751 | 3300 XL Multi-Purpose Stainless Steel Housing (12”x12”x6”), supports up to 8 DIN-mount or 6 panel-mount Proximitor Sensors |
| 176467 | 3300 XL Multi-Purpose Stainless Steel Housing (12”x8”x6”), supports up to 4 Proximitor Sensors in DIN or panel mount configuration |
| 330181 | 3300 XL Multi-Purpose Stainless Steel Housing (13”x9.5”x7”), supports up to 8 DIN-mount or 6 panel-mount sensors, hazardous area certified options available |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire |
| 138492-01 | Replacement panel-mount mounting pad |
| 138493-01 | Replacement DIN-mount mounting pad |
| 148722-01 | 3300 XL test plug with 3 test pins and color-coded leads for sensor performance testing without removing field wiring |
| 04310310 | Panel-mount screw for 3300 XL Proximitor Sensor, 6-32 UNC thread forming screw (4 required per sensor) |
| 03200006 | Silicone self-fusing tape roll (9.1 m) for connector protection and electrical insulation |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables including tools |
| 136536-01 | Connector protector adapter for compatibility with older installation tools |
| 40180-02 | Connector protectors package (10 pairs) for environmental sealing of probe and cable connectors |
| 03839410 | 75Ω triaxial male connector protector for extension cable side protection |
| 03839420 | 75Ω triaxial female connector protector for probe lead or Proximitor sensor connection protection |
| 04301007 | 3/8-24 probe lock nut with safety wire holes for secure installation |
| 04301008 | M10 x 1 probe lock nut with safety wire holes for secure probe fixation |
| 330153-01 | 3300 XL connector kit including male/female ClickLoc connectors, sleeves, tubing, and silicone tape |
