Product Name:3300 XL 8 mm Proximity Probes
Brand Name:BENTLY NEVADA
Model Number:330103-05-13-10-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330103-05-13-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Specification |
|
Model |
330103-05-13-10-02-00 |
|
Series |
3300 XL 8 mm Proximity Probe |
|
Thread Type |
M10 x 1 metric |
|
Probe Type |
Non-contact eddy current sensor |
|
Cable Length |
0.5 m – 9.0 m selectable |
|
Case Length |
20 mm – 250 mm configurable |
|
Unthreaded Length |
0 – 230 mm |
|
Connector Type |
ClickLoc coaxial connector |
|
Armor Option |
With / Without armor |
|
Operating Temp |
-52°C to +177°C |
|
Dimension (Approx.) |
2x1.5x115cm |
|
Weight |
0.1kg |
The 330103-05-13-10-02-00 is a high-performance eddy current sensor designed for precise vibration and shaft position monitoring in industrial rotating machinery. Built within the 3300 XL series architecture, it delivers stable, accurate, and repeatable measurements under demanding operating environments.
The 330103-05-13-10-02-00 probe supports non-contact measurement technology, ensuring reliable signal output proportional to the distance between the probe tip and conductive target surface. It is widely used in turbine systems, compressors, pumps, and generator sets for real-time condition monitoring and protection.
Engineered for interchangeability and API 670 compliance, this probe integrates seamlessly with 3300 XL extension cables and Proximitor sensors, providing flexible installation, strong EMI resistance, and long-term operational stability in critical automation systems.
Power plants: Generator vibration monitoring and turbine protection systems.
Substations: Busbar protection, switching signal acquisition, and relay monitoring.
Chemical plants: Process automation and intrinsic safety signal detection.
Steel mills: Equipment control in high-temperature and EMI-heavy environments.
Machinery manufacturing: Automated production lines, robotics, and packaging control.
Q1: What is the main function of 330103-05-13-10-02-00?
A1: It is used for non-contact vibration and position measurement of rotating machinery.
Q2: Is it compatible with other 3300 XL components?
A2: Yes, it is fully compatible with 3300 XL Proximitor sensors and extension cables.
Q3: Can it operate in high-temperature environments?
A3: Yes, it supports operation up to 177°C under standard conditions.
Q4: What industries commonly use this probe?
A4: Power generation, petrochemical, steel manufacturing, and automation industries.
Q5: Does it support armored cable options?
A5: Yes, it is available in both armored and non-armored configurations.
| Number | Describe |
|---|---|
| 148722-01 | 3300 XL test plug with 3 color-coded 1-meter wires and banana plugs for Proximitor sensor performance testing |
| 04310310 | 3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread forming mounting screw |
| 03200006 | Silicone self-fusing tape for connector insulation and environmental protection |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables with installation tools |
| 136536-01 | Connector protector adapter for pre-1998 installation tools and 75Ω ClickLoc connectors |
| 40180-02 | Connector protectors package containing 10 pairs for 3300 XL 8 mm probes and extension cables |
| 03839410 | 75Ω triaxial male connector protector for environmental protection of extension cable connections |
| 03839420 | 75Ω triaxial female connector protector for probe lead and Proximitor sensor connection protection |
| 04301007 | 3/8-24 probe lock nut with safety wire holes for secure probe mounting |
| 04301008 | M10 × 1 probe lock nut with safety wire holes for secure installation |
| 330153-01 | 3300 XL connector kit with male/female ClickLoc connectors, sleeves, FEP tubing, and silicone tape |
