Product Name: 3300 XL 8 mm Proximity Probe
Brand Name: Bently Nevada
Model Number: 330103-10-20-05-02-CN
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | Bently Nevada 330103-10-20-05-02-CN 3300 XL 8 mm Proximity Probe |
| Manufacturer | Bently Nevada |
| Product Type | 3300 XL 8 mm Proximity Probe |
| Part Number | 330103-10-20-05-02-CN |
| Estimated shipping dimensions | 1.8x1.5x69cm |
| Weight | 0.1kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Probe Relative Humidity | Less than a 3% change in Average Scale Factor (ASF) when tested in 93% humidity in accordance with IEC standard 68 2 3 for up to 56 days. |
| Frequency Response | (0 to 10 kHz), +0, -3 dB, with up to 305 meters (1000 feet) of field wiring. |
| Unthreaded Length Option | 100 mm |
| Overall Case Length Option | 200 mm |
| Total Length Option | 0.5 meter (1.6 feet) |
| Connector and Cable-Type Option | Miniature coaxial ClickLoc connector, standard cable |
The Bently Nevada 330103-10-20-05-02-CN is part of the 3300 XL 8 mm Proximity Transducer System, designed for precise vibration, position, Keyphasor reference, and speed monitoring in industrial rotating machinery. It works with a matching extension cable and Proximitor® sensor to produce a voltage output proportional to the distance between the probe tip and the conductive target surface, enabling accurate non-contact measurement of both static and dynamic conditions.
This model incorporates advanced mechanical protection features such as patented TipLoc molding, which strengthens the probe tip bond, and CableLoc technology, which provides high cable retention strength up to 330 N (75 lbf). An optional FluidLoc cable design further enhances reliability by preventing fluid ingress in oil-prone or pressurized environments. With an unthreaded length of 100 mm, an overall case length of 200 mm, and a 0.5 m cable with a miniature coaxial ClickLoc connector, it is designed for stable installation and secure signal transmission.
High Structural Reliability
The Bently Nevada 330103-10-20-05-02-CN uses TipLoc and CableLoc technologies to ensure strong mechanical bonding and secure cable retention, improving durability in high-vibration environments.
Enhanced Environmental Protection
Optional FluidLoc cable design prevents oil and liquid ingress, making the probe suitable for harsh, fluid-prone industrial conditions.
High Measurement Stability
It delivers consistent and accurate vibration and position signals with minimal variation, even under long cable runs up to 305 meters.
Wide System Compatibility
The probe is fully API 670 compliant and supports interchangeability with other 3300 XL and legacy 3300 series components without recalibration.
Flexible Installation Design
Multiple mechanical and cable configurations allow easy integration into different machine types and monitoring setups.
Reliable Signal Transmission
The miniature coaxial ClickLoc connector ensures stable and low-loss signal transfer for continuous monitoring applications.
The Bently Nevada 330103-10-20-05-02-CN delivers high-frequency, high-accuracy vibration and position measurement with a frequency response range of 0 to 10 kHz (+0, -3 dB), ensuring precise monitoring of fast-changing dynamic conditions in rotating machinery. Its eddy-current sensing technology provides stable voltage output proportional to target distance, supporting reliable condition monitoring in fluid-film bearing systems and turbine applications.
Engineered for harsh industrial environments, the probe maintains measurement stability even under extreme humidity conditions, showing less than a 3% change in Average Scale Factor after 56 days at 93% relative humidity. It also supports long-distance field wiring up to 305 meters while preserving signal integrity, making it highly efficient for large-scale industrial monitoring systems.
The system improves operational efficiency through its modular 3300 XL architecture, allowing seamless interchangeability between probes, cables, and Proximitor® sensors without the need for recalibration. Combined with robust mechanical protection technologies like TipLoc, CableLoc, and optional FluidLoc, it reduces maintenance needs and enhances long-term operational reliability.
1. Is the 330103-10-20-05-02-CN interchangeable with other probes?
Yes. The 330103-10-20-05-02-CN is fully interchangeable with other 3300 XL and legacy 3300 series components.
2. What system is the 330103-10-20-05-02-CN part of?
The 330103-10-20-05-02-CN is part of the 3300 XL 8 mm Proximity Transducer System, including a probe, extension cable, and Proximitor® sensor.
3. What makes the 330103-10-20-05-02-CN mechanically durable?
The 330103-10-20-05-02-CN uses TipLoc molding and CableLoc technology to strengthen the probe structure and improve cable retention strength.
4. Can the 330103-10-20-05-02-CN be used in oil or fluid environments?
Yes. The 330103-10-20-05-02-CN supports optional FluidLoc cables that prevent fluid ingress into the cable system.
5. What is the frequency response of the 330103-10-20-05-02-CN?
The 330103-10-20-05-02-CN supports a frequency response of 0 to 10 kHz (+0, -3 dB).
6. How far can the signal be transmitted?
The 330103-10-20-05-02-CN supports field wiring up to 305 meters while maintaining signal integrity.
