Bently Nevada 330104-00-04-05-02-00 3300 XL 8 mm Proximity Probe

Bently Nevada 330104-00-04-05-02-00 3300 XL 8 mm Proximity Probe

Product Name: 3300 XL 8 mm Proximity Probe

Brand Name: Bently Nevada

Model Number: 330104-00-04-05-02-00

Place of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

bently nevada 330104 00 04 05 02 00 3300 xl 8 mm proximity probe-1

Overview
Commercial Terms
Description
Functions
Specifications
Advantage
Performance & Efficiency
Installation & Integration
Recommended Products

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Description

The Bently Nevada 330104-00-04-05-02-00 is a 3300 XL 8 mm proximity probe designed for highly reliable vibration and position monitoring in rotating machinery. Built with a compact 40 mm overall case length and 0.5 meter (1.6 feet) total cable length, it offers flexible installation in space-constrained environments while maintaining stable measurement accuracy. Its miniature coaxial ClickLoc connector with standard cable ensures secure electrical connection and low signal loss in demanding industrial conditions.

Engineered for long-term operational stability, the probe features a nominal DC resistance of 7.45 ± 0.50 Ω, along with 50 Ω output resistance and 10 kΩ load resistance compatibility for broad system integration. It is designed to maintain less than a 3% change in Average Scale Factor (ASF) under high humidity conditions (93% RH, IEC 68-2-3), ensuring dependable performance in harsh and moisture-prone environments. Advanced TipLoc and CableLoc technologies further enhance mechanical integrity, while optional FluidLoc protection prevents fluid ingress into the cable system.

Functions

Measures shaft vibration in rotating and fluid-film bearing machinery.
Monitors shaft position and dynamic displacement in real time.
Converts mechanical motion into proportional electrical signals for analysis.
Supports Keyphasor® and speed measurement applications.
Enables continuous condition monitoring of critical rotating equipment.
Provides stable signal transmission across long field wiring distances.
Supports early detection of faults such as imbalance, misalignment, and looseness.
Integrates into machinery protection and predictive maintenance systems.
Maintains measurement accuracy under high humidity and harsh operating conditions.

Specifications

Product Name	Bently Nevada 330104-00-04-05-02-00 3300 XL 8 mm Proximity Probe
Manufacturer	Bently Nevada
Product Type	3300 XL 8 mm Proximity Probe
Part Number	330104-00-04-05-02-00
Weight	0.8kg
Estimated shipping dimensions	1.8x1.5x59cm
Place of shipment	Xiamen, China
Country of origin	USA
Minimum unthreaded length	0 mm
Overall Case Length Option	40 mm
Total Length Option	0.5 meter (1.6 feet)
Connector and Cable-Type Option	Miniature coaxial ClickLoc connector, standard cable
Agency Approval Option	Not required
Nominal Probe DC Resistance	7.45 ± 0.50 Ω
Maximum Altitude	2000 meters
Load Resistance	10 kΩ
Output Resistance	50 Ω
Probe Relative Humidity	Less than a 3% change in Average Scale Factor (ASF) when tested in 93% humidity in accordance with IEC standard 68 2 3 for up to 56 days.
Frequency Response	(0 to 10 kHz), +0, -3 dB, with up to 305 meters (1000 feet) of field wiring.

Advantage

High measurement reliability with stable electrical characteristics (7.45 ± 0.50 Ω DC resistance).
Robust TipLoc design strengthens probe tip bonding for improved mechanical durability.
CableLoc structure provides 330 N (75 lbf) pull strength for secure cable retention.
Optional FluidLoc cable prevents fluid ingress, extending probe lifespan.
Excellent environmental resistance with <3% ASF variation under high humidity testing.
Wide frequency response (0–10 kHz) supports accurate dynamic vibration analysis.
Long-distance signal integrity maintained up to 305 m (1000 ft) field wiring.
Compact design enables installation in tight or complex machinery spaces.
Compatible with standard 3300 XL system architecture for easy integration.
Suitable for high-reliability industrial monitoring and protection applications.

Performance & Efficiency

Delivers accurate vibration and displacement measurement across full 8 mm sensing range.
Maintains stable performance under extreme humidity conditions per IEC 68-2-3 testing.
Supports high-frequency response up to 10 kHz for detailed dynamic analysis.
Ensures consistent signal quality even over extended wiring distances.
Provides reliable operation at altitudes up to 2000 meters.
Enhances predictive maintenance efficiency through accurate real-time monitoring.
Reduces signal degradation and improves long-term measurement stability.
Supports continuous operation in demanding industrial environments.

Installation & Integration

The Bently Nevada 330104-00-04-05-02-00 probe is designed for straightforward installation using its compact 40 mm case and M10 × 1 threaded mounting interface, allowing secure integration into rotating machinery housings. It connects easily to Bently Nevada 3300 XL extension cables and Proximitor sensors via a miniature coaxial ClickLoc connector, ensuring fast, reliable electrical connection with minimal signal loss. Its 0.5 meter cable length supports flexible routing in constrained installations, while its high environmental resistance and mechanical reinforcement features make it suitable for both new installations and retrofit applications in harsh industrial environments.
