Product Name:IO Extender module
Brand Name:Honeywell
Model Number:FC-IO-0001
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
FC-IO-0001 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Specification |
|
Product Model |
FC-IO-0001 |
|
Module Type |
IO Extender Module |
|
System |
Safety Manager |
|
Function |
IO communication bridge |
|
Power Supply |
5 V DC |
|
Power Consumption |
35 mA |
|
Ripple |
< 50 mV p-p |
|
Slot Requirement |
4 TE / 3 HE |
|
Connector Type |
DIN 41612 Type F |
|
Installation |
IO chassis mounted |
|
Address Control |
CA0–CA3 jumper settings |
|
Operating Role |
Control Processor to IO transfer |
|
Dimensions |
2x19x12.8cm |
|
Weight |
0.12kg |
The FC-IO-0001 IO Extender Module is a key communication interface used in Safety Manager systems to link the Control Processor with distributed IO modules inside the IO chassis. It ensures reliable data transfer across non-redundant and redundant architectures, supporting stable industrial automation performance.
In standard configurations such as IOCHAS-0001S, a single FC-IO-0001 module is installed in slot 21, while redundant setups like IOCHAS-0001R use dual modules in slots 20 and 21 to maintain continuous system communication. The module connects through CN1 and CN3 interfaces and integrates with chassis backplane bus structures.
Designed for safety-critical environments, the FC-IO-0001 supports flexible addressing via jumper settings and maintains robust IO bus communication integrity in demanding process control applications.
Q1: What is the FC-IO-0001 used for?
A1: It is used to connect the Control Processor with IO modules in Safety Manager systems.
Q2: Can FC-IO-0001 operate in redundant systems?
A2: Yes, it supports both redundant and non-redundant IO chassis configurations.
Q3: Where is the FC-IO-0001 installed?
A3: It is installed inside the IO chassis, typically in slot 21 or dual slots 20–21.
Q4: How is the chassis address configured?
A4: The address is set using CA0–CA3 jumper settings on the IO backplane.
Q5: What is the power requirement of FC-IO-0001?
A5: It operates on a 5 V DC supply with approximately 35 mA consumption.
