Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330104-00-15-10-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330104-00-15-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Details |
|---|---|
| Product Model | 330104-00-15-10-02-00 |
| Series | 3300 XL 8 mm Proximity Probe |
| Thread Type | M10 x 1 |
| Total Length | 1.5 m system cable |
| Cable Type | Armored triaxial cable |
| Connector | Gold-plated ClickLoc connector |
| Output Type | Eddy current proximity signal |
| Measurement Range | 0.25 mm – 2.3 mm linear range |
| Operating Temp | -52°C to +177°C |
| Material | Stainless steel probe body |
| Weight | ~0.7 kg system approx. |
| Dimension | 8 mm probe diameter standard |
The330104-00-15-10-02-00is a high-performance part of the 3300 XL 8 mm proximity probe series, designed for accurate vibration and position monitoring in industrial rotating machinery. As part of the Bently Nevada 3300 XL system, including models like330103and330104, it delivers reliable eddy current measurement for critical asset protection and condition monitoring applications.
Built with rugged stainless-steel construction and precision sensing technology, the330104-00-15-10-02-00ensures stable signal output even in harsh operational environments. Its armored design improves mechanical durability, while ClickLoc connectors provide secure and fast installation with reduced maintenance effort.
This probe is fully compatible with 3300 XL extension cables and Proximitor sensors, offering interchangeability without recalibration. It is widely used in turbine systems, compressors, pumps, and other high-speed rotating equipment requiring continuous monitoring and high accuracy performance.
Q1: What is the main use of 330104-00-15-10-02-00?
A1: It is used for vibration and shaft position measurement in rotating machinery.
Q2: Is 330104-00-15-10-02-00 compatible with 3300 XL systems?
A2: Yes, it is fully compatible with Bently Nevada 3300 XL probes and sensors.
Q3: Can it operate in harsh environments?
A3: Yes, its armored design supports high temperature and industrial conditions.
Q4: What type of connector does it use?
A4: It uses a gold-plated ClickLoc connector for secure installation.
Q5: Does it require calibration after replacement?
A5: No, it is fully interchangeable with standard 3300 XL components.
| Number | Describe |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual |
| 175751 | 3300 XL Multi-Purpose Stainless Steel Housing 12"x12"x6", supports up to 8 Proximitor Sensors (DIN mount) or 6 (panel mount), ATEX Zone 0/1 certified |
| 176467 | 3300 XL Multi-Purpose Stainless Steel Housing 12"x8"x6", supports up to 4 Proximitor Sensors, DIN or panel mount, ATEX Zone 0/1 certified |
| 330181 | 3300 XL Multi-Purpose Stainless Steel Housing 13"x9.5"x7", supports up to 8 sensors (DIN) or 6 (panel), hazardous area approvals, ATEX Zone 0/1, North American Division 1/2 certified |
| 02120015 | Bulk field wire 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, length customizable |
| 138492-01 | Replacement panel-mount mounting pad for 3300 XL systems |
| 138493-01 | Replacement DIN-mount mounting pad for 3300 XL systems |
| 148722-01 | 3300 XL test plug with 3-pin adapter and banana plugs for Proximitor sensor testing without removing field wiring |
| 04310310 | 3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread, 4 screws required per sensor |
| 03200006 | Silicone self-fusing tape roll (9.1 m) for connector protection and environmental insulation |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, includes tools and protectors |
| 136536-01 | Connector protector adapter for compatibility with pre-1998 installation tools |
| 40180-02 | Connector protectors pack (10 pairs) for 3300 XL 8 mm probes and extension cables |
| 03839410 | 75Ω triaxial male connector protector for environmental sealing of probe cable connections |
