Bently Nevada 330104-00-20-05-02-00 3300 XL 8 mm Proximity Probe

Bently Nevada 330104-00-20-05-02-00 3300 XL 8 mm Proximity Probe

Product Name: 3300 XL 8 mm Proximity Probe

Brand Name: Bently Nevada

Model Number: 330104-00-20-05-02-00

Place of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

bently nevada 330104 00 20 05 02 00 3300 xl 8 mm proximity probe-1

Overview
Commercial Terms
Description
Functions
Specifications
Advantage
Performance & Efficiency
Installation & Integration
Recommended Products

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Description

The Bently Nevada 330104-00-20-05-02-00 is a 3300 XL 8 mm proximity probe engineered for high-precision vibration and position measurement in rotating machinery. Featuring an M10 × 1 threaded and armored construction with a 200 mm overall case length and 0.5 meter (1.6 feet) total cable length, it is designed to deliver stable, reliable performance in real-time monitoring applications. Its compact configuration makes it suitable for space-constrained installations while maintaining measurement accuracy in demanding industrial environments.

As part of the Bently Nevada 3300 XL 8 mm proximity measurement system, the probe operates in conjunction with an extension cable and Proximitor sensor to produce an output voltage proportional to the distance between the probe tip and the conductive target. With low power supply sensitivity (<2 mV output variation per volt input change) and a nominal DC resistance of 7.45 ± 0.50 Ω, it ensures long-term signal stability and dependable performance for critical machinery monitoring applications.

Functions

Measures shaft vibration in rotating and fluid-film bearing machinery.
Monitors shaft position and dynamic displacement in real time.
Supports Keyphasor® and rotational speed measurement applications.
Converts distance variations into proportional electrical voltage signals.
Enables continuous condition monitoring of critical rotating equipment.
Supports interchangeability within the 3300 XL system (probe, cable, and sensor).
Facilitates machinery protection through early fault detection.
Provides stable measurement output for both static and dynamic analysis.
Supports compliance with API 670 requirements for machinery protection systems.

Specifications

Product Name	Bently Nevada 330104-00-20-05-02-00 3300 XL 8 mm Proximity Probe
Manufacturer	Bently Nevada
Product Type	3300 XL 8 mm Proximity Probe
Part Number	330104-00-20-05-02-00
Weight	0.12kg
Estimated shipping dimensions	1.8x1.5x59cm
Place of shipment	Xiamen, China
Country of origin	USA
Minimum unthreaded length	0 mm
Overall Case Length Option	200 mm
Total Length Option	0.5 meter (1.6 feet)
Connector and Cable-Type Option	Miniature coaxial ClickLoc connector, standard cable
Nominal Probe DC Resistance	7.45 ± 0.50 Ω
Supply Sensitivity	Less than 2 mV change in output voltage per volt change in input voltage.

Advantage

High measurement precision for vibration and displacement monitoring.
Excellent signal stability with low sensitivity to power supply fluctuations.
Compact 0.5 m configuration suitable for tight installation spaces.
Rugged M10 × 1 threaded and armored design ensures mechanical durability.
Fully compatible with the 3300 XL interchangeable system architecture.
Eliminates need for individual system calibration during component replacement.
Supports standardized spare parts management and simplified maintenance.
API 670 compliant design ensures reliability in critical applications.
Suitable for continuous operation in harsh industrial environments.
Enhances operational safety through reliable machinery condition monitoring.

Performance & Efficiency

Provides accurate proximity measurement with a nominal DC resistance of 7.45 ± 0.50 Ω.
Maintains output stability with less than 2 mV variation per volt of supply change.
Ensures consistent signal output for both vibration and position monitoring.
Delivers reliable performance in real-time monitoring of rotating machinery.
Supports long-term measurement accuracy without recalibration during component interchange.
Enhances predictive maintenance efficiency through stable data acquisition.
Reduces system downtime by enabling fast and reliable component replacement.
Optimized for high-reliability industrial monitoring environments.

Installation & Integration

The Bently Nevada 330104-00-20-05-02-00 probe is designed for straightforward installation using its M10 × 1 threaded mounting interface, allowing secure integration into a wide range of rotating machinery applications. It connects seamlessly with Bently Nevada 3300 XL extension cables and Proximitor sensors through a miniature coaxial ClickLoc connector, ensuring reliable electrical contact and ease of assembly. Its compact 0.5 meter cable length supports flexible routing in confined spaces, while its interchangeable system design enables direct replacement of probes, cables, or sensors without the need for recalibration, simplifying maintenance and system upgrades in industrial monitoring installations.
