Product Name:3300 XL 8 mm Proximity Probes
Brand Name:BENTLY NEVADA
Model Number:330103-00-14-10-01-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330103-00-14-10-01-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Details |
|---|---|
| Model | 330103-00-14-10-01-00 |
| System Type | 3300 XL 8 mm Proximity Probe |
| Probe Diameter | 8 mm |
| Thread Type | M10 x 1 |
| Output Type | Eddy current analog voltage |
| Measurement Range | 0.25 mm – 2.3 mm linear range |
| Operating Temperature | -52°C to +177°C |
| Cable Type | 75Ω triaxial shielded cable |
| Installation Type | Forward/reverse mount compatible |
| Dimension (Probe Length) | 0.5 m – 9 m configurable |
| Unthreaded Length | 0 – 230 mm (configurable) |
| Weight | ~323 g/m (probe dependent) |
| Material | Stainless steel (SST) probe case |
The330103-00-14-10-01-00is a high-precision 3300 XL 8 mm proximity probe designed for accurate vibration and position monitoring in industrial machinery. It works as part of the3300 XL 8 mm Proximity Transducer System, delivering stable eddy-current measurements for rotating equipment such as turbines, compressors, and motors. This model supports reliable signal output proportional to the distance between probe tip and conductive target surface.
Built for harsh environments, the330103-00-14-10-01-00offers strong mechanical durability with stainless steel construction and advanced sensing stability. It is compatible with extension cables and Proximitor sensors in the 3300 XL series, ensuring flexible integration and system interchangeability without recalibration.
Engineered for industrial reliability, the3300 XL 8 mm probe seriessupports API 670 compliance, making it ideal for predictive maintenance systems. It is widely used in vibration monitoring, shaft position detection, and machine protection applications.
Q1: What is the 330103-00-14-10-01-00 used for?
A1: It is used for vibration, position, and shaft monitoring in rotating industrial machinery systems.
Q2: Is the probe compatible with other 3300 XL components?
A2: Yes, it is fully compatible with 3300 XL extension cables and Proximitor sensors.
Q3: Can it operate in high-temperature environments?
A3: Yes, it supports operating temperatures up to 177°C in standard conditions.
Q4: Does this probe require calibration after installation?
A4: No, system interchangeability eliminates the need for bench calibration.
Q5: What industries commonly use this probe?
A5: It is widely used in power plants, petrochemical facilities, steel mills, and manufacturing automation.
| number | describe |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual |
| 175751 | 3300 XL Multi-Purpose Stainless Steel Housing 12”x12”x6”, supports up to 8 DIN-mount or 6 panel-mount Proximitor sensors, ATEX Zone 0/1 certified |
| 176467 | 3300 XL Multi-Purpose Stainless Steel Housing 12”x8”x6”, supports up to 4 Proximitor sensors in DIN or panel mount configuration, ATEX Zone 0/1 certified |
| 330181 | 3300 XL Multi-Purpose Stainless Steel Housing 13”x9.5”x7”, supports up to 8 DIN-mount or 6 panel-mount Proximitor sensors, ATEX Zone 0/1 and North American Division 1/2 certified |
| 02120015 | Bulk field wire 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, length customizable |
| 138492-01 | Replacement panel-mount mounting pad for Proximitor sensor installation |
| 138493-01 | Replacement DIN-mount mounting pad for Proximitor sensor installation |
| 148722-01 | 3300 XL test plug with 3-pin adapter and 1-meter color-coded wires for Proximitor sensor testing without removing field wiring |
| 04310310 | 3300 XL Proximitor Sensor panel-mount screw set, 6-32 UNC thread forming screws, 4 required per sensor |
| 03200006 | Silicone self-fusing tape, 9.1 m roll for connector insulation and environmental protection |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables including installation tools |
| 136536-01 | Connector protector adapter enabling compatibility with pre-1998 installation tools for 75Ω ClickLoc connectors |
| 40180-02 | Connector protectors package, 10 pairs for 3300 XL 8 mm probes and extension cables |
| 03839410 | 75Ω triaxial male connector protector for extension cable-to-probe connection environmental sealing |
| 03839420 | 75Ω triaxial female connector protector for probe lead and extension cable environmental protection |
| 04301007 | 3/8-24 probe lock nut with safety wire holes for secure mechanical installation |
