Product Name: 3300 XL 8 mm Proximity Probe
Brand Name: Bently Nevada
Model Number: 330104-06-14-10-02-00
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Tag
| Eddy Current Displacement Probe | Generator Monitoring Sensor |
| Vibration Monitoring Sensor | Keyphasor Compatible Probe |
| Shaft Position Probe | Speed Measurement Probe |
| Rotating Machinery Monitoring Probe | Noncontact Eddy Current Probe |
| Fluid Film Bearing Probe | Predictive Maintenance Sensor |
| API 670 Compliant Probe | 3300 XL Transducer System Component |
| Industrial Condition Monitoring Probe | Harsh Environment Probe |
| Turbine Vibration Probe | Backward Compatible 3300 Series Probe |
| Compressor Monitoring Probe | High Stability Industrial Probe |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | Bently Nevada 330104-06-14-10-02-00 3300 XL 8 mm Proximity Probe |
| Manufacturer | Bently Nevada |
| Product Type | 3300 XL 8 mm Proximity Probe |
| Part Number | 330104-06-14-10-02-00 |
| Estimated shipping dimensions | 1.8x1.5x121cm |
| Weight | 0.18kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Unthreaded Length Option | 60 mm |
| Overall Case Length Option | 140 mm |
| Total Length Option | 1.0 meter (3.3 feet) |
| Connector and Cable-Type Option | Miniature coaxial ClickLoc connector, standard cable |
| Agency Approval Option | Not required |
| Nominal Probe DC Resistance | 7.59 ± 0.50 Ω |
| Probe Relative Humidity | Less than a 3% change in Average Scale Factor (ASF) when tested in 93% humidity in accordance with IEC standard 68 2 3 for up to 56 days. |
The Bently Nevada 330104-06-14-10-02-00 is a 3300 XL 8 mm eddy current proximity probe designed for high-precision vibration and position measurement in fluid-film bearing machinery. It is part of the complete 3300 XL transducer system, which includes the probe, extension cable, and Proximitor® sensor, and provides accurate measurement of both static shaft position and dynamic vibration.
This probe system is engineered for demanding industrial environments such as turbines, compressors, pumps, and generators. It generates an output voltage directly proportional to the distance between the probe tip and the conductive target surface, enabling reliable monitoring of shaft behavior, including vibration, displacement, Keyphasor reference, and speed measurement functions.
Fully compliant with API 670 standards, the system ensures high accuracy, linearity, and temperature stability. It also offers full interchangeability between probes, cables, and Proximitor sensors without requiring bench calibration or component matching, supporting both new installations and retrofit applications in industrial machinery monitoring.
The 330104-06-14-10-02-00 probe operates as a passive eddy current sensing device and does not require any software, firmware, or electronic programming. It functions through electromagnetic coupling between the probe tip and the conductive surface to generate a proportional voltage signal.
It is installed as part of a complete measurement chain consisting of the probe, extension cable, and Proximitor® sensor. Proper mechanical installation, including correct mounting position, alignment, and connector engagement, is essential to ensure accurate signal transmission and stable performance.
Each probe is assigned to a dedicated measurement channel within the monitoring system for vibration, position, or speed measurement of a specific machine location. It operates directly within the Bently Nevada 3300 XL system architecture without any configuration steps required.
The probe is factory-calibrated and designed for standardized interchangeability across compatible system components. Measurement accuracy depends on correct physical installation and system integration rather than any programmable parameters or software settings.
