Bently Nevada 330106-XX-XX-10-02-00 MOD:145628-01 3300 XL 8 mm Reverse Mount Probes In stock

Bently Nevada 330106-XX-XX-10-02-00 MOD:145628-01 3300 XL 8 mm Reverse Mount Probes In stock

Product Name:3300 XL 8 mm Reverse Mount Probes

Brand Name:Bently Nevada

Model Number:330106-XX-XX-10-02-00 MOD:145628-01

Country of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

bently nevada 330106 xx xx 10 02 00 mod145628 01 3300 xl 8 mm reverse mount probes in stock-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Bently Nevada
Model Number:	330106-XX-XX-10-02-00 MOD:145628-01
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Description
Model	330106-XX-XX-10-02-00 (MOD:145628-01)
Series	Bently Nevada 3300 XL 8 mm
Probe Type	Reverse mount eddy current probe
Thread	M10 x 1
Measurement Range	0.25–2.3 mm linear range
Cable Type	Standard / FluidLoc optional
Connector	ClickLoc coaxial connector
Material	Stainless steel probe body
Operating Temp	-52°C to +177°C
Dimension	1.3x1.3x113cm
Weight	0.06kg
Installation	Reverse mount configuration

Description

The 330106-XX-XX-10-02-00 (MOD:145628-01) is a Bently Nevada 3300 XL 8 mm reverse mount proximity probe designed for high-accuracy vibration and position monitoring in rotating machinery. It uses advanced eddy-current sensing technology to deliver stable, non-contact measurement of shaft movement in critical industrial environments.

As part of the 3300 XL reverse mount probe series, including compatible variants such as 330105 and 330106, this model ensures full interchangeability with extension cables and Proximitor sensors. Its M10 x 1 threaded structure and FluidLoc-compatible cable options provide strong mechanical integrity and protection against environmental contamination in demanding installations.

Engineered for API 670 compliance, the 330106-XX-XX-10-02-00 offers excellent linear performance, EMI resistance, and long-term signal stability, making it suitable for turbines, compressors, pumps, and other mission-critical rotating equipment monitoring applications.

Applications

Power plants: Used for generator set status monitoring and relay protection.
Substations (substations): Enable bus differential control, line protection, and switchyard signal acquisition.
Chemical plants: Integrate process control automation and intrinsically safe signal monitoring.
Steel mills (metallurgical plants): Perform equipment logic control in high-temperature and high-EMI environments.
Machinery manufacturing plants: Used for automated production lines, robotic workstations, and packaging equipment control.

Features

Reverse mount configuration for flexible installation
High-precision eddy current measurement technology
Fully interchangeable 3300 XL system architecture
Rugged stainless steel probe construction
FluidLoc option for enhanced fluid resistance
API 670 compliant industrial performance

Functions

Shaft vibration monitoring
Axial and radial displacement measurement
Machinery condition diagnostics
Speed and Keyphasor signal output
Industrial protection system input signal

FAQ

Q1: What is the 330106-XX-XX-10-02-00 used for?
A1: It is used for vibration and position measurement in rotating machinery systems.

Q2: Is it compatible with other 3300 XL components?
A2: Yes, it is fully compatible with 3300 XL extension cables and Proximitor sensors.

Q3: What is the benefit of reverse mount design?
A3: It allows easier installation in confined spaces and improves mounting flexibility.

Q4: Can it be used in harsh environments?
A4: Yes, it is designed for high temperature, vibration, and EMI-intensive industrial conditions.

Q5: Does it require recalibration after replacement?
A5: No, it supports full interchangeability without the need for recalibration.

Spares

Number	Description
04310310	3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread-forming mounting screw; four screws required per sensor, supplied with panel-mount housings.
03200006	Silicone self-fusing tape, 9.1 m roll, used for connector protection, provides electrical insulation and environmental sealing.
40113-02	Connector Protector Kit for 3300 XL 8 mm probes and extension cables, includes protectors and installation tools.
136536-01	Connector protector adapter, allows use of pre-1998 installation tools with 75Ω ClickLoc connectors.
40180-02	Connector protectors package, includes 10 pairs for 3300 XL 8 mm probes and extension cables.
03839410	75Ω triaxial male connector protector, provides environmental protection for extension cable connections.
03839420	75Ω triaxial female connector protector, protects probe and extension cable connections from environmental exposure.
04301007	3/8-24 probe lock nut with safety wire holes, designed to secure probe installation with safety wire.
04301008	M10 x 1 probe lock nut with safety wire holes, used to secure probe installation in industrial applications.
330153-01	3300 XL connector kit including male/female ClickLoc connectors, sleeves, slit FEP tubing, and silicone tape.
330153-09	3300 XL ETR connector kit for high-temperature applications, includes connectors, high-temp tubing, and silicone tape.
163356	Connector Crimp Tool Kit with multi-connector inserts and installation instructions, compatible with 330153 kits.
