Product Name: 3300 XL Standard Extension Cable
Brand Name: Bently Nevada
Model Number: 330130-040-02-CN
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | Bently Nevada 330130-040-02-CN 3300 XL Standard Extension Cable |
| Manufacturer | Bently Nevada |
| Product Type | 3300 XL Standard Extension Cable |
| Part Number | 330130-040-02-CN |
| Estimated shipping dimensions | 21x21x1.5cm |
| Weight | 0.16kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Cable Length Option | 4.0 meters (11.5 feet) |
| Connector Protector and Cable Option | Standard cable with connector protector |
| Nominal Extension Cable DC Resistance | 0.88 ± 0.13 Ω |
| Maximum Altitude for Specs | 2000 meters |
| Load Resistance | 10 kΩ |
The Bently Nevada 330130-040-02-CN is a 3300 XL 8 mm extension cable designed to form a critical part of an eddy current proximity measurement system. With a cable length of 4.0 meters (11.5 feet), it is used to connect the proximity probe to the Proximitor sensor, ensuring stable signal transmission within rotating machinery monitoring setups. The cable is built with a standard configuration including a connector protector to enhance durability and environmental resistance.
As part of the 3300 XL series, this extension cable is engineered to meet the requirements of industrial vibration and position monitoring systems. It is designed to maintain signal integrity across the full measurement chain while supporting accurate displacement and vibration data acquisition. Its robust construction allows it to operate reliably in demanding industrial environments.
The primary function of the 330130-040-02-CN extension cable is to transmit electrical signals from the proximity probe to the Proximitor sensor without degradation. It ensures that the eddy current signal remains stable and accurately represents the distance between the probe tip and the target surface. This allows precise measurement of both static shaft position and dynamic vibration.
In addition to signal transmission, the cable provides electrical length consistency and system calibration support. It helps maintain the correct total system electrical length, which is essential for accurate linear response and measurement accuracy across the full operating range. Any deviation in electrical length can affect system performance and may require recalibration.
The cable also contributes to noise resistance and signal stability in industrial environments. By maintaining proper shielding and grounding practices, it supports reliable operation even in high electromagnetic interference conditions, ensuring continuous monitoring performance.
The 330130-040-02-CN is fully compatible with the Bently Nevada 3300 XL 8 mm proximity probe and Proximitor sensor system. It is designed to function as the standard interconnect cable within the measurement chain, ensuring seamless integration and consistent system performance. It maintains compatibility with the full 3300 XL architecture for vibration and position monitoring.
It also supports backward compatibility with non-XL 5 mm and 8 mm probe systems, allowing integration into legacy installations without requiring full system replacement. This enables flexible upgrades and mixed-system configurations in industrial environments.
The cable is engineered to maintain correct electrical length calibration across the complete system. When used with matched probe and sensor components, it ensures stable measurement accuracy and reliable long-term operation in critical monitoring applications.
