Product Name: 3300 XL Standard Extension Cable
Brand Name: Bently Nevada
Model Number: 330130-040-10-CN
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | Bently Nevada 330130-040-10-CN 3300 XL Standard Extension Cable |
| Manufacturer | Bently Nevada |
| Product Type | 3300 XL Standard Extension Cable |
| Part Number | 330130-040-10-CN |
| Estimated shipping dimensions | 18x18x1.5cm |
| Weight | 0.14kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Cable Length Option | 4.0 meters (11.5 feet) |
| Connector Protector and Cable Option | FluidLoc cable |
| Nominal Extension Cable DC Resistance | 0.88 ± 0.13 Ω |
| Resistance (RJACKET ) from Outer Conductor to Outer Conductor | 0.26 ± 0.05 Ω |
| Operating and Storage Temperature | -52°C to +177°C (-62°F to +350°F) |
The Bently Nevada 330130-040-10-CN is a 3300 XL 8 mm extension cable designed as a critical interconnect component within eddy current proximity transducer systems. It features a 4.0-meter (11.5-foot) cable length and a FluidLoc cable design, ensuring reliable signal transmission while preventing the ingress or leakage of fluids through the cable structure. This makes it suitable for demanding industrial environments where oil exposure or contamination risks are present.
As part of the 3300 XL extension cable family, this model is engineered to maintain high measurement integrity between the proximity probe and Proximitor sensor. It supports stable operation in vibration and position monitoring applications, ensuring consistent system performance across a wide range of industrial conditions. Its rugged construction and sealed design enhance long-term reliability.
The primary function of the 330130-040-10-CN extension cable is to transmit low-level eddy current signals from the proximity probe to the Proximitor sensor with high fidelity. It preserves signal integrity and ensures that the measured displacement values accurately represent the distance between the probe and the conductive target surface. This is essential for reliable vibration and shaft position monitoring.
In addition to signal transmission, the cable maintains controlled electrical resistance and impedance characteristics, including a nominal DC resistance of 0.88 ± 0.13 Ω and a jacket resistance (RJACKET) of 0.26 ± 0.05 Ω. These parameters help ensure measurement accuracy and reduce signal distortion across the full monitoring system.
The FluidLoc design also performs a protective function by preventing oil or other liquids from migrating through the cable. This safeguards the integrity of the electrical connection and helps maintain long-term stability in harsh or contaminated industrial environments.
The Bently Nevada 330130-040-10-CN extension cable is fully compatible with the 3300 XL 8 mm eddy current proximity transducer system. It is designed to operate between the 3300 XL proximity probe and the 3300 XL Proximitor sensor, forming an integral part of the complete measurement chain used for vibration and shaft position monitoring. When used with matching 3300 XL system components, it ensures stable signal transmission and consistent measurement accuracy.
It is engineered to maintain full system interoperability within the 3300 XL architecture, meaning it can be directly integrated into existing configurations without requiring custom calibration or special matching procedures. The cable preserves correct electrical length characteristics across the system, which is essential for maintaining linear response and accurate displacement measurement. This ensures reliable operation when paired with standard 3300 XL probes and monitoring modules.
In addition to full compatibility within the 3300 XL series, the 330130-040-10-CN also supports backward compatibility with earlier non-XL 5 mm and 8 mm proximity probe systems. This allows it to be used in retrofit applications where legacy monitoring systems are upgraded or expanded. Its standardized design enables flexible installation in both new and existing industrial monitoring environments while maintaining system stability and measurement integrity.
