Bently Nevada 330100-90-00 Proximitor Sensor Original new, China Bently Nevada 330100-90-00 Proximitor Sensor Original new Manufacturers, Suppliers, Factory

Overview

Brand Name:	Bently Nevada
Model Number:	330100-90-00
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Model Number	330100-90-00
Product Type	Proximitor Sensor
System Length	9.0 meters (29.5 ft)
Input Compatibility	3300 XL 8 mm / 3300 5 mm probes
Operating Voltage	-17.5 Vdc to -26 Vdc
Power Consumption	12 mA maximum
Output Resistance	50 Ω
Linear Range	2 mm (80 mils)
Frequency Response	0 to 6.5 kHz
Housing Material	A383 Aluminum
Operating Temperature	-51°C to +100°C
Storage Temperature	-51°C to +100°C
Weight	0.28kg
Dimension	7.8x6x4.8cm

Description

330100-90-00is a reliableBently Nevada 3300 Proximitor Sensordesigned for precision shaft vibration, axial position, and displacement monitoring in rotating machinery. As a core element of the 3300 Proximity Transducer System, it converts probe signals into stable voltage outputs proportional to target distance, helping operators maintain accurate machine condition data.

Engineered for demanding industrial environments,330100-90-00supports a9.0 meter total system lengthand offers excellent linearity, repeatability, and temperature stability. It is commonly paired with compatible probes and extension cables such as3300 XL 8 mm,3300 5 mm, and330130 seriescables for dependable long-term operation.

Widely used in turbines, compressors, pumps, motors, and generators,330100-90-00helps improve predictive maintenance programs, reduce unexpected shutdowns, and optimize asset reliability. Its rugged construction and easy interchangeability make it a preferred replacement sensor for legacy 3300 monitoring systems.

Applications

Power plants:Used for turbine shaft vibration monitoring and generator rotor position detection.
Oil & gas facilities:Supports compressors, pumps, and critical rotating assets.
Chemical plants:Ensures continuous condition monitoring in process machinery.
Steel mills:Protects motors, fans, and rolling equipment from vibration faults.
Paper mills:Monitors high-speed rolls and drive systems.
Water treatment plants:Used on pumps and blower systems.
Manufacturing plants:Supports predictive maintenance programs for rotating machines.

Features

High accuracy displacement signal conversion
Stable output across wide temperature ranges
Supports 9 m transducer system configuration
Compatible with multiple 3300 probes
Rugged aluminum housing
Easy installation and replacement
Ideal for legacy system upgrades
Strong resistance to industrial interference

Functions

Converts probe gap signal into proportional voltage output
Measures shaft vibration amplitude
Detects axial movement and position change
Supports continuous machine health monitoring
Sends signals to monitoring/control systems
Helps prevent unplanned machinery failures

FAQ

Q1: What is 330100-90-00 used for?
A1: It is used for vibration, displacement, and shaft position monitoring on rotating equipment.

Q2: What system length does 330100-90-00 support?
A2: This model is designed for a 9.0 meter total transducer system length.

Q3: Is 330100-90-00 compatible with 3300 XL probes?
A3: Yes, it works with compatible 3300 XL 8 mm and 3300 5 mm probes.

Q4: Can this model replace older 3300 sensors?
A4: Yes, it is commonly used as a replacement in existing 3300 systems.

Q5: Where is 330100-90-00 commonly installed?
A5: It is widely installed on turbines, compressors, motors, pumps, and generators.

Spares

Number	Description
86130-01	Manual
155687	Performance Specification
132501-AXX	1.0 mm² (18 AWG), 3-conductor twisted shielded field wiring cable for Proximitor sensor to monitor connection with terminal ring lugs
02120015	Bulk field wire 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, length specified in feet
02173009	Bulk field wire 1.0 mm² (18 AWG), 3-conductor twisted shielded cable, length specified in feet
137491-AXX	Aluminum probe clamp bracket for smooth case probe mounting with threaded options and safety wire screws
137492-AXX	Aluminum probe mounting bracket for standard 3300/3300 XL probe installations with multiple thread size options
27474-AXX	Phenolic probe mounting bracket for electrical isolation applications in generator and motor bearing installations
330951-01	Proximitor sensor mounting screws package (4 pcs)
03200006	Silicone self-fusing tape roll for connector protection and environmental sealing
40113-02	Connector protector kit for 3300 XL probes and extension cables
136536-01	Connector protector adapter for compatibility between legacy kits and 3300 XL connectors
40180-02	Connector protectors package (10 pairs)
03839410	Male connector protector for extension cable environmental sealing
03839420	Female connector protector for probe and sensor connection protection
04301007	3/8-24 probe lock nut with safety wire holes
04301008	M10 x 1 probe lock nut with safety wire holes
330152-01	3300 XL connector kit with ClickLoc connectors and silicone tape
136540-01	Connector crimp tool kit with 75 Ω ClickLoc inserts and installation instructions
