Product Name:Extension Cable
Brand Name:Bently Nevada
Model Number:330190-035-00-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330190-035-00-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Model Number | 330190-035-00-00 |
| Product Type | Extended Temperature Range (ETR) Extension Cable |
| Cable Length | 3.5 m (11.5 ft) |
| Cable Option | Standard Cable |
| Agency Approval | Not Required |
| Compatible System | 3300 XL 8 mm Proximity Transducer System |
| Cable Construction | 75 Ω Triaxial PFA Insulated Cable |
| Maximum Operating Temperature | Up to 260°C (500°F) |
| Minimum Operating Temperature | -52°C (-62°F) |
| Connector Type | Gold-Plated ClickLoc Connectors |
| Minimum Bend Radius | 25.4 mm (1.0 in) |
| Dimension | Length: 3.5 m; Cable Diameter Approx. 8 mm |
| Weight | Approx. 0.12 kg (Typical) |
| Shielding | Triaxial Shielded Design |
| Installation Type | Probe-to-Proximitor Sensor Connection |
Bently Nevada 330190-035-00-00is a high-performance Extended Temperature Range (ETR) extension cable engineered for use within the renowned 3300 XL proximity transducer system. Designed with a 3.5-meter cable length, this model ensures reliable signal transmission between the proximity probe and Proximitor sensor while maintaining measurement accuracy in demanding industrial environments.
As part of the330190 Series, the330190-035-00-00extension cable supports vibration monitoring, shaft position detection, speed sensing, and machinery protection applications. Its robust construction and compatibility with3300 XL 8 mm probes,330130 extension cables, and other Bently Nevada transducer components make it a preferred solution for critical rotating equipment monitoring systems.
Built for extended temperature operation, the330190-035-00-00helps maintain dependable performance in turbines, compressors, generators, pumps, and process machinery where elevated temperatures and harsh operating conditions are common. The cable contributes to stable signal integrity, reduced maintenance requirements, and long-term system reliability across industrial asset management applications.
Power Plants:Used in turbine monitoring systems, generator protection networks, and critical rotating machinery applications where stable vibration and position measurements are essential.
Oil & Gas Facilities:Supports compressors, pumps, gas turbines, and other process equipment requiring continuous condition monitoring and predictive maintenance.
Chemical Plants:Provides reliable signal transmission for machinery health monitoring in high-temperature and corrosive industrial environments.
Steel Mills:Applied in rolling mills, heavy-duty motors, and metallurgical equipment operating under severe temperatures and electromagnetic interference.
Petrochemical Facilities:Enables accurate shaft displacement and vibration monitoring for mission-critical process equipment and production assets.
Machinery Manufacturing Plants:Integrated into automated production lines, robotic systems, testing platforms, and industrial machine monitoring solutions.
Mining Operations:Supports equipment protection and condition-based maintenance programs for crushers, conveyors, and large rotating machinery.
Marine & Offshore Platforms:Suitable for propulsion systems, compressors, generators, and auxiliary equipment requiring dependable machinery monitoring in harsh environments.
Q1: What is the primary function of the 330190-035-00-00 extension cable?
A1: It connects a 3300 XL proximity probe to a Proximitor sensor while ensuring accurate signal transmission for vibration and position measurements.
Q2: What is the cable length of the 330190-035-00-00?
A2: The cable provides a total extension length of 3.5 meters (approximately 11.5 feet).
Q3: Can the 330190-035-00-00 operate in high-temperature environments?
A3: Yes, the ETR cable is designed to withstand temperatures up to 260°C (500°F).
Q4: Which systems are compatible with the 330190-035-00-00?
A4: It is designed for use with Bently Nevada 3300 XL 8 mm proximity transducer systems and compatible monitoring components.
Q5: What industries commonly use the 330190-035-00-00 extension cable?
A5: Power generation, oil & gas, petrochemical, chemical processing, steel manufacturing, and industrial automation industries frequently utilize this cable for machinery condition monitoring.
| Number | Description |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual. |
| 175751 | 3300 XL Multi-Purpose Stainless Steel Housing, 12" × 12" × 6", supports up to 8 DIN-mounted or 6 panel-mounted Proximitor Sensors, available with ATEX Zone 0 and Zone 1 certifications. |
| 176467 | 3300 XL Multi-Purpose Stainless Steel Housing, 12" × 8" × 6", supports up to 4 Proximitor Sensors in DIN-mount or panel-mount configurations, available with ATEX Zone 0 and Zone 1 certifications. |
| 330181 | 3300 XL Multi-Purpose Stainless Steel Housing, 13" × 9.5" × 7", supports up to 8 DIN-mounted or 6 panel-mounted Proximitor Sensors, suitable for hazardous area installations with ATEX and North American certifications. |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, length specified by customer. |
| 138492-01 | Replacement panel-mount mounting pad. |
| 138493-01 | Replacement DIN-mount mounting pad. |
| 148722-01 | 3300 XL Test Plug with color-coded wires and banana plugs for performance testing without disconnecting field wiring. |
| 04310310 | Panel-mount screw for 3300 XL Proximitor Sensor, 6-32 UNC thread-forming type, four required per sensor. |
| 03200006 | Silicone self-fusing tape for connector protection, electrical insulation, and environmental sealing. |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including protectors and installation tools. |
| 136536-01 | Connector protector adapter for compatibility with pre-1998 installation tools and 75Ω ClickLoc connectors. |
| 40180-02 | Package containing 10 pairs of connector protectors for 3300 XL probes and extension cables. |
| 03839410 | 75Ω triaxial male connector protector for environmental protection of extension cable connections. |
| 03839420 | 75Ω triaxial female connector protector for protecting probe and Proximitor sensor connections from environmental exposure. |
