Bently Nevada 3500/23E Transient Data Interface In stock, China Bently Nevada 3500/23E Transient Data Interface In stock Manufacturers, Suppliers, Factory

Overview

Brand Name:	Bently Nevada
Model Number:	3500/23E
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	3500/23E
Product Type	Transient Data Interface (TDI) Module
Brand	Bently Nevada
System Compatibility	3500 ENCORE System
Communication Protocols	Ethernet, Modbus
Installation Position	Adjacent to Power Supply Slot
Ethernet Ports	Front and rear Ethernet connectivity
Keyphasor Support	Up to 4 Keyphasor transducers
LED Indicators	RACK OK, CONFIG OK, TDI OK, TRIP MULTIPLY
Alarm/Event Storage	1000 alarms and 400 system events
Configuration Security	Keylock switch and password protection
Reset Function	Front-panel system reset switch
Dimension	5.5x29x23cm
Approximate Weight	1.44kg
Application Environment	Industrial machinery protection systems

Description

Bently Nevada3500/23ETransient Data Interface (TDI) module is a critical communication and control interface designed for the advanced3500 ENCOREmachinery protection platform. Installed beside the power supply slot, the module serves as the central connection point between monitoring hardware, configuration software, and plant automation systems. It supports high-speed data transmission, rack configuration, condition monitoring, and remote diagnostics for industrial rotating equipment.

The3500/23Emodule enables seamless integration withSystem 1machinery management software and supports industry-standard communication protocols including Modbus over Ethernet. Compatible with monitoring modules such as3500/42E,3500/45E,3500/50E, and3500/61E, it provides reliable access to real-time machine condition data and alarm information.

Designed for continuous online monitoring applications, the3500/23Eimproves operational reliability in turbines, compressors, generators, pumps, and other critical machinery used in power generation, petrochemical processing, steel production, and heavy industrial automation environments.

Applications

Power plants:Used for turbine monitoring systems, generator protection, and machinery condition management.
Substations:Supports industrial communication and equipment status integration within automation systems.
Chemical plants:Provides continuous machinery monitoring and process automation data communication.
Steel mills:Enables reliable operation in high-temperature and high-electromagnetic-interference environments.
Machinery manufacturing plants:Applied in automated production equipment diagnostics and rotating machinery monitoring.
Oil & gas facilities:Integrates compressor and pump monitoring into centralized plant control systems.
Marine and offshore industries:Supports critical rotating equipment protection and remote diagnostics.

Features

Central communication interface for 3500 ENCORE systems
Supports Ethernet and Modbus communication
Compatible with multiple 3500 monitor modules
Provides real-time machinery status monitoring
Integrated alarm and event management functions
Front and rear Ethernet connectivity
Secure configuration with password and keylock protection
Supports remote diagnostics and maintenance access

Functions

Connects monitoring modules with control systems
Transfers real-time vibration and machinery data
Supports rack configuration and system diagnostics
Provides alarm and event recording capabilities
Enables remote system monitoring through Ethernet
Supports Keyphasor signal integration
Enhances machinery protection and predictive maintenance efficiency

FAQ

Q1:What is the main function of the3500/23Emodule?
A1:It acts as the central communication and interface module for the 3500 ENCORE monitoring system.

Q2:Which communication protocols are supported by the3500/23E?
A2:The module supports Ethernet and Modbus communication protocols.

Q3:Can the3500/23Econnect with System 1 software?
A3:Yes, it provides direct integration with Bently Nevada System 1 machinery management software.

Q4:How many Keyphasor transducers can the3500/23Esupport?
A4:The module can support up to four Keyphasor transducers per rack.

Q5:Is the3500/23Esuitable for industrial machinery protection systems?
A5:Yes, it is designed for continuous online monitoring of critical rotating machinery in industrial environments.

Spares

Number	Description
3500/05E	Instrument Chassis for the 3500 ENCORE system, supporting rack-based machinery monitoring installations.
3500/15E	Power Supply module available in AC, low-voltage DC, or high-voltage DC input versions.
3500/23E	Transient Data Interface (TDI) module used for system communication, configuration, and monitoring integration.
3500 Rack Configuration Software	Software platform used for rack setup, module configuration, and system management.
3500/42E	Four-channel vibration monitor module supporting radial vibration, axial position, eccentricity, differential expansion, acceleration, velocity, and shaft absolute measurements.
3500/45E	Four-channel position monitor module supporting thrust position, differential expansion, case expansion, and valve position monitoring.
3500/50E	Two-channel tachometer module designed for speed, rotor acceleration, zero-speed, and reverse rotation measurements.
3500/61E	Six-channel temperature monitor module for industrial temperature monitoring applications.
3500/67E	Two-channel temperature monitor module designed for machinery and process temperature measurements.
