Product Name:3300 XL 11 mm Proximitor Sensor
Brand Name:Bently Nevada
Model Number:330780-51-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330780-51-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Description |
|
Model Number |
330780-51-00 |
|
Series |
3300 XL 11 mm Proximitor Sensor |
|
System Length |
5.0 meters (standard configuration) |
|
Mounting Type |
DIN rail mount |
|
Supply Voltage |
-17.5 Vdc to -26 Vdc |
|
Power Consumption |
Max 12 mA |
|
Operating Temperature |
-52°C to +100°C (-62°F to +212°F) |
|
Storage Temperature |
-52°C to +105°C (-62°F to +221°F) |
|
Housing Material |
A380 aluminum alloy |
|
Weight |
Approx. 255 g |
|
Dimensions |
Compact DIN rail footprint (industrial standard form factor) |
|
Certifications |
CE, RoHS, FCC, IECEx / ATEX (optional) |
The 330780-51-00 is a high-performance Bently Nevada 3300 XL 11 mm Proximitor Sensor designed for precision non-contact vibration and position monitoring in industrial rotating machinery. As part of the 3300 XL 11 mm Proximity Transducer System, it works with matching probes and extension cables to deliver stable, high-accuracy displacement signals for critical asset protection applications.
Built with advanced EMI/RFI immunity and a compact DIN-rail or panel-mount design, the 330780-51-00 ensures reliable operation in electrically noisy and harsh industrial environments. It features SpringLoc terminals for fast wiring, improved signal stability, and compatibility with modern control and protection systems.
This model is widely used in turbines, compressors, and pumps for axial position, vibration, and Keyphasor reference measurements. The system supports seamless integration in upgrade projects, replacing legacy 7200-series sensors with improved accuracy and long-term stability.
Q1: What is the 330780-51-00 used for?
A1: It is used for precise vibration and position monitoring in rotating machinery systems.
Q2: Which system is compatible with 330780-51-00?
A2: It is fully compatible with the Bently Nevada 3300 XL 11 mm proximity transducer system.
Q3: Can it be installed on DIN rail systems?
A3: Yes, the 330780-51-00 is designed for both DIN rail and panel mounting.
Q4: What industries commonly use this sensor?
A4: It is widely used in power plants, chemical plants, steel mills, and machinery manufacturing.
Q5: Does it support harsh environment operation?
A5: Yes, it features strong EMI/RFI resistance and supports industrial-grade operating conditions.
| Number | Describe |
|---|---|
| 146255 | 3300XL 11 mm User Guide |
| 144979 | Performance Specification |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor, twisted, shielded cable with drain wire, specify length in feet |
| 02173009 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor, twisted, shielded cable, specify length in feet |
| 138492-01 | Replacement panel-mount mounting pad |
| 138493-01 | Replacement DIN-mount mounting pad |
| 01609137 | BNC (F) to banana plugs adapter |
| 01609138 | Proximitor connector test pin wiring (two test pins to BNC (F) connector) |
| 40971-04 | 50 Ω cable with two BNC (M) connectors for transducer system testing |
| 04310310 | 3300XL Proximitor Sensor panel-mount screws (4 pcs, 6-32 UNC) |
| 03200006 | Silicone self-fusing tape roll (9.1 m) for connector protection |
| 40113-02 | Connector protector kit for 3300 XL probes and extension cables |
| 136536-01 | Connector protector adapter for compatibility with older connector kits |
| 40180-02 | Connector protectors package (10 pairs) |
| 03839410 | Male connector protector for environmental sealing |
| 03839420 | Female connector protector for probe and extension cable protection |
| 330153-01 | 3300 XL connector kit (male/female ClickLoc connectors, sleeves, silicone tape) |
| 163356 |
Connector crimp tool kit for 75 Ω ClickLoc connector installation |
