Product Name: 3300 XL 8 mm Probe
Brand Name: Bently Nevada
Model Number: 330196-05-30-10-CN
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Tag
| 3300 XL 8 mm Reverse Mount Probe | Generator Shaft Probe |
| Extended Temperature Proximity Probe (ETR) | Keyphasor Compatible Probe |
| Eddy Current Displacement Sensor | Speed Measurement Probe |
| Vibration Monitoring Probe | Rotating Machinery Sensor |
| Shaft Position Measurement Probe | API 670 Compliant Probe System |
| Industrial Condition Monitoring Probe | Harsh Environment Probe |
| Fluid Film Bearing Probe | Stainless Steel Industrial Probe |
| Turbine Monitoring Sensor | Predictive Maintenance Sensor |
| Compressor Vibration Probe | High Temperature Cable System Probe |
| Pump Monitoring Probe | Noncontact Eddy Current Probe |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | Bently Nevada 330196-05-30-10-CN 3300 XL 8 mm Probe |
| Manufacturer | Bently Nevada |
| Product Type | 3300 XL 8 mm Probe |
| Part Number | 330196-05-30-10-CN |
| Estimated shipping dimensions | 1.1x1x111cm |
| Weight | 0.06kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Total Length Option | 1.0 metre (3.3 feet) |
| Output resistance | 50 Ω |
| Probe dc resistance (nominal) (RPROBE) table | 7.59 ± 0.50 ohms |
| Probe case torque | Maximum Rated: 22.6 N•m (200 in•lbf); Recommended: 7.5 N•m (66 in•lbf). |
| Operating and Storage Temperature | -51 °C to +177 °C (-60 °F to +351 °F) for the probe tip; -51 °C to +260 °C (-60 °F to +500 °F) for the probe cable and connector. |
| power supply | -24 Vdc |
The Bently Nevada 330196-05-30-10-CN is a 3300 XL 8 mm extended temperature range (ETR) reverse-mount proximity probe designed for accurate vibration and position measurement in rotating machinery. It is part of the 3300 XL proximity transducer system and is optimized for applications requiring high reliability under extreme environmental and thermal conditions.
This model features a 1.0-meter integrated cable and an M10 × 1 threaded reverse-mount configuration, ensuring secure installation in fluid-film bearing machinery such as turbines, compressors, pumps, and generators. It delivers precise noncontact eddy current measurements proportional to the distance between the probe tip and the conductive target surface.
Engineered for harsh industrial environments, the probe supports extended temperature operation up to 177°C at the tip and up to 260°C for the cable and connector assembly. It is compatible with Keyphasor and speed measurement applications and complies with API 670 requirements for accuracy, linearity, and system interchangeability.
The 330196-05-30-10-CN probe operates as a passive eddy current sensing device and does not require any software, firmware, or electronic programming. Its operation is based entirely on electromagnetic interaction between the probe tip and the conductive surface being monitored.
It is installed as part of a complete measurement chain consisting of the probe, extension cable, and Proximitor® sensor. Correct mechanical installation, including proper mounting torque, alignment, and connector engagement, is essential to ensure stable and accurate signal transmission.
Each probe is assigned to a dedicated measurement channel within the monitoring system for vibration, position, or speed monitoring of a specific machine location. It operates directly within the Bently Nevada 3300 XL system architecture without any configuration steps required.
The probe is factory-calibrated and designed for standardized interchangeability across compatible systems. Measurement performance depends on correct physical installation and system integration rather than any programmable parameters or software settings.
