Product Name:3300 XL 11 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330703-000-040-10-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330703-000-040-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Details |
|---|---|
| Product Model | 330703-000-040-10-02-00 |
| Series | 3300 XL 11 mm Proximity Probe |
| Thread Type | M14 x 1.5 |
| Probe Type | Unarmored configuration |
| System Compatibility | 3300 XL 11 mm Proximitor Sensor |
| Output Sensitivity | 3.94 V/mm (100 mV/mil) |
| Frequency Range | 0 – 8 kHz |
| Linear Range | Approx. 4.0 mm |
| Cable Type | Coaxial extension compatible |
| Material | Stainless steel probe body |
| Operating Temp | -52°C to +177°C |
| Storage Temp | -52°C to +177°C |
| Dimension (L) | Depends on configuration (up to 250 mm case range) |
| Weight | Approx. 70 g (base probe, varies by length) |
The330703-000-040-10-02-00is part of theBently Nevada 3300 XL 11 mm Proximity Probeseries, designed for precise non-contact vibration and displacement monitoring in rotating machinery. It is widely used in turbine, compressor, and industrial monitoring systems where extended linear range and stable signal output are required.
As a member of theBently Nevada 3300 XL 11 mm Proximity Transducer System, this probe supports threaded mounting configurations and can be integrated with armored or unarmored cable options. Its robust mechanical structure ensures reliable operation in high-vibration and harsh industrial environments.
Combined with theBently Nevada 3300 XL 11 mm Proximitor Sensor, it delivers high accuracy signal conversion for axial position, shaft vibration, and keyphasor measurements. The system is optimized for long-term stability and industrial-grade monitoring performance.
Q1:What system is the 330703 probe compatible with?
A1:It is designed for the Bently Nevada 3300 XL 11 mm proximity transducer system.
Q2:What is the main use of this proximity probe?
A2:It is used for vibration, displacement, and shaft position monitoring in rotating machinery.
Q3:Can it operate in harsh industrial environments?
A3:Yes, it is designed for high temperature, high vibration, and EMI-prone conditions.
Q4:Does it support different cable configurations?
A4:Yes, it supports standard, armored, and FluidLoc cable options depending on installation needs.
Q5:What type of measurements can it provide?
A5:It supports radial vibration, axial position, and keyphasor signal measurements.
| Number | Describe |
|---|---|
| 146255 | 3300XL 11 mm User Guide |
| 144979 | Performance Specification |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor, twisted, shielded cable with drain wire, specify length in feet |
| 02173009 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor, twisted, shielded cable, specify length in feet |
| 138492-01 | Replacement panel-mount mounting pad |
| 138493-01 | Replacement DIN-mount mounting pad |
| 01609137 | BNC (F) to banana plugs |
| 01609138 | Proximitor connector test pin wiring (two test pins to a BNC (F) connector) |
| 40971-04 | 50 Ω cable with two BNC (M) connectors for transducer system testing |
| 04310310 | 3300XL Proximitor Sensor panel-mount screws (4 pcs, 6-32 UNC) |
| 03200006 | Silicone self-fusing tape (9.1 m roll) for connector protection and insulation |
| 40113-02 | Connector protector kit for 3300 XL probes and extension cables |
| 136536-01 | Connector protector adapter for compatibility with older 3300 systems |
| 40180-02 | Connector protectors (package of 10 pairs) |
| 03839410 | Male connector protector for environmental protection of probe connections |
