Product Name:3300 NSv Proximity Probes
Brand Name:Bently Nevada
Model Number:330902-04-48-10-02-00
Country of Origin:USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330902-04-48-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Details |
|---|---|
| Model | 330902-04-48-10-02-00 |
| Series | Bently Nevada 3300 XL NSv |
| Probe Type | Eddy current proximity probe |
| Thread Type | 1/4-28 UNF |
| Cable Type | Coaxial NSv cable |
| Total Length | 1.0–5.0 m configurable |
| Linear Range | 1.5 mm (60 mils) |
| Operating Temperature | -52°C to +177°C |
| Material | Stainless steel probe body |
| Weight | ~110–140 g |
| Dimensions | 1/4-28 threaded compact industrial probe |
The 330902-04-48-10-02-00 is a Bently Nevada 3300 NSv proximity probe designed for compact rotating machinery where installation space is limited. It operates as part of the eddy current transducer system, delivering stable, high-precision vibration and position measurements for industrial monitoring and protection applications.
Built within the 3300 XL NSv series, models such as 330901, 330902, and 330908 are optimized for tight-clearance environments like compressors, turbines, and small shaft assemblies. The probe’s rugged mechanical structure ensures reliable signal output even in high-vibration and restricted mounting conditions.
When combined with NSv extension cables and Proximitor sensors, the system provides consistent performance and interchangeability. It is widely applied in condition monitoring systems, supporting accurate detection of shaft displacement, vibration trends, and machinery health diagnostics in critical industries.
Q1: What is the 330902 NSv probe used for?
A1: It is used for measuring vibration and shaft position in compact rotating machinery systems.
Q2: Is the 330902 compatible with 3300 XL systems?
A2: Yes, it is fully compatible with Bently Nevada 3300 XL NSv Proximitor sensors and extension cables.
Q3: What industries commonly use this probe?
A3: It is widely used in power plants, compressors, steel mills, and chemical processing facilities.
Q4: Can it operate in harsh environments?
A4: Yes, it is designed for high temperature, vibration, and chemically aggressive industrial conditions.
Q5: What type of signal does it provide?
A5: It provides non-contact eddy current displacement signals for vibration and position monitoring.
| Number | Description |
|---|---|
| 147357 | 3300 XL NSv Proximitor User Guide |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire. Specify length in feet. |
| 138492-01 | Replacement panel-mount mounting pad |
| 138493-01 | Replacement DIN-mount mounting pad |
| 01609137 | BNC (F) to banana plugs adapter |
| 01609138 | Proximitor connector test pin wiring (two test pins to BNC (F) connector) |
| 40971-04 | 50 Ω cable with two BNC (M) connectors. Used with adapters 01609137 and 01609138 for system performance testing via Proximitor test pins |
| 04310310 | 3300 XL Proximitor sensor panel-mount screw kit (6-32 UNC thread forming screw included) |
| 03200006 | Silicone self-fusing tape, 9.1 m (10 yard) roll for connector protection and electrical insulation |
| 40113-03 | Connector Protector Kit for 3300 NSv probes and extension cables including installation tools |
| 136536-01 | Connector Protector Adapter for compatibility with pre-1998 installation tools and 75 Ω ClickLoc connectors |
| 40180-03 | Connector Protectors, package of 10 pairs for environmental sealing of probe and extension cable connectors |
| 03800000 | Male connector protector for extension cable, used with female connector protector on probe for environmental sealing |
