Product Name:8mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330104-00-05-05-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330104-00-05-05-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Specification |
|
Model |
330104-00-05-05-02-00 |
|
Brand |
Bently Nevada |
|
Product Type |
3300 XL 8 mm Proximity Probe |
|
Thread Type |
M10 x 1 |
|
Cable Type |
Standard Cable |
|
Armor |
Without Armor |
|
Total Length |
0.5 meter |
|
Probe Diameter |
8 mm |
|
Housing Material |
Stainless Steel (AISI 303/304) |
|
Tip Material |
PPS (Polyphenylene Sulfide) |
|
Operating Temperature |
-52°C to +177°C |
|
Cable Capacitance |
69.9 pF/m |
|
Weight |
0.08kg |
The Bently Nevada 330104-00-05-05-02-00 is a precision-engineered 3300 XL 8 mm proximity probe designed for accurate vibration and shaft position monitoring in rotating machinery. As part of the 3300 XL series, it integrates seamlessly with compatible extension cables and Proximitor sensors to deliver stable and reliable signal output in demanding industrial environments such as turbines, compressors, and pumps.
Built with a rugged M10 x 1 threaded stainless steel housing, 330104-00-05-05-02-00 ensures secure installation and long-term mechanical durability. Its eddy current sensing technology converts distance variations into proportional voltage signals, enabling both static position and dynamic vibration measurement with high precision. This makes it ideal for continuous condition monitoring applications.
The 3300 XL 8 mm probe 330104-00-05-05-02-00 is fully compatible with API 670 compliant systems and supports interchangeability across the 3300 series platform. It provides excellent temperature stability, improved noise immunity, and reliable performance in critical asset protection systems used in power generation, petrochemical, and heavy manufacturing industries.
Q1: What is the main function of 330104-00-05-05-02-00?
A1: It is used for measuring vibration and shaft position in rotating machinery.
Q2: Is 330104-00-05-05-02-00 compatible with 3300 XL systems?
A2: Yes, it is fully compatible with Bently Nevada 3300 XL Proximitor systems.
Q3: Does this probe support industrial harsh environments?
A3: Yes, it is designed for high vibration, oil exposure, and temperature variation.
Q4: What type of connector does it use?
A4: It uses a gold-plated ClickLoc connector system for secure connection.
Q5: Can it be used in power plants and turbines?
A5: Yes, it is widely used in turbines, generators, and other power plant equipment.
| Number | Describe |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual |
| 175751 | 3300 XL Multi-Purpose Stainless Steel Housing, 12”x12”x6”, holds up to 8 DIN-mount or 6 panel-mount Proximitor Sensors, ATEX Zone 0 / Zone 1 available |
| 176467 | 3300 XL Multi-Purpose Stainless Steel Housing, 12”x8”x6”, holds up to 4 Proximitor Sensors in DIN-mount or panel-mount configuration |
| 330181 | 3300 XL Multi-Purpose Stainless Steel Housing, 13”x9.5”x7”, holds up to 8 DIN-mount or 6 panel-mount Proximitor Sensors, hazardous area certified |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3 conductor, twisted shielded cable with drain wire |
| 138492-01 | Replacement panel-mount mounting pad |
| 138493-01 | Replacement DIN-mount mounting pad |
| 148722-01 | 3300 XL test plug with 3 color-coded 1-meter wires and banana plugs for sensor performance testing |
| 04310310 | 3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread forming screw |
| 03200006 | Silicone self-fusing tape, 9.1-meter roll for connector insulation and environmental protection |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables with installation tools |
| 136536-01 | Connector protector adapter for pre-1998 installation tools with 75Ω ClickLoc connectors |
| 40180-02 | Connector protectors, package of 10 pairs for 3300 XL 8 mm probes and extension cables |
| 03839410 | 75Ω triaxial male connector protector for extension cable environmental protection |
| 03839420 | 75Ω triaxial female connector protector for probe lead or sensor connection protection |
| 04301007 | 3/8-24 probe lock nut with safety wire holes |
| 04301008 | M10 x 1 probe lock nut with safety wire holes |
| 330153-01 | 3300 XL connector kit with ClickLoc connectors, sleeves, FEP tubing, and silicone tape |
| 330153-09 | 3300 XL ETR connector kit for high-temperature probes and extension cables |
| 163356 | Connector Crimp Tool Kit with inserts, instructions, and carrying case |
