Product Name:Temperature Modules
Brand Name:Bently Nevada
Model Number:3500/60
Country of Origin:USA
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
3500/60 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Product Model | 3500/60 & 3500/61 |
| Product Type | Temperature Monitoring Module |
| Channels | 6 channels |
| Supported Inputs | RTD & Thermocouple (TC) |
| Input Impedance | 10 MΩ per lead input |
| Power Consumption | 3500/60: 7 W / 3500/61: 9 W |
| RTD Types | 100Ω Pt (α=0.00385 / 0.00392), 120Ω Nickel, 10Ω Copper |
| Thermocouple Types | Type E, J, K, T |
| RTD Measurement Range | -200°C to +850°C (type dependent) |
| TC Measurement Range | -160°C to +1370°C (type dependent) |
| Cold Junction Compensation | ±1°C accuracy at 25°C |
| System Isolation | 500 Vdc |
| Channel-to-Channel Isolation | 250 Vdc (isolated I/O modules) |
| Output Signal | 4–20 mA recorder output (3500/61 only) |
| Resolution | 1°C / 1°F |
| Accuracy | ±1°C to ±3°C (configuration dependent) |
| Alarm Setpoints | 0–100% full-scale (Alert & Danger) |
| Alarm Delay | Alert: 1–60 s / Danger: 1–60 s |
| LED Indicators | OK / TX-RX / Bypass |
| Operating Temperature | -30°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | 241.3 × 24.4 × 241.8 mm |
| Weight | 0.91 kg (module) |
| Configuration Method | 3500 Rack Configuration Software |
| Communication | 3500 rack backplane |
| Safety Integrity Level | SIL 2 |
| Certifications | ATEX, IECEx, CSA, CE, EMC, RoHS, DNV GL |
| Application | Machinery protection, turbine monitoring, industrial temperature monitoring |
The Bently Nevada 3500/60 and 3500/61 Temperature Modules are advanced monitoring units designed for multi-channel industrial temperature acquisition and protection. These modules support up to six input channels and are compatible with RTD and thermocouple sensors, providing flexible configuration for diverse machinery monitoring requirements in modern industrial systems.
The 3500/60 focuses on reliable temperature measurement and alarm processing, while the 3500/61 extends functionality by adding dedicated recorder outputs for each channel. Both models integrate seamlessly into the Bently Nevada 3500 monitoring platform, ensuring stable signal conditioning, high accuracy, and real-time diagnostic capability.
Configured via 3500 Rack Configuration Software, the 3500/60 / 3500/61 modules support isolated and non-isolated I/O options, making them suitable for harsh industrial environments. These modules are widely used in turbine systems, rotating equipment, and process industries requiring precise thermal condition monitoring and early fault detection.
Power plants: Used for turbine and generator temperature monitoring, ensuring safe thermal operation and alarm protection.
Substations: Enables transformer winding temperature supervision, bus system monitoring, and fault detection.
Chemical plants: Supports process temperature control and hazardous area thermal safety monitoring systems.
Steel mills: Provides reliable thermal monitoring in high-temperature furnaces and heavy industrial environments.
Machinery manufacturing plants: Applied in automated production lines for equipment temperature tracking and protection control.
Q1: What is the main function of the 3500/60 module?
A1: It provides multi-channel temperature monitoring and alarm protection for industrial machinery using RTD and thermocouple inputs.
Q2: What is the difference between 3500/60 and 3500/61?
A2: The 3500/61 includes recorder outputs for each channel, while the 3500/60 focuses only on monitoring and alarm functions.
Q3: Can the module support mixed RTD and thermocouple inputs?
A3: Yes, it can be configured to accept RTD, thermocouple, or mixed sensor inputs depending on system setup.
Q4: Is channel isolation available for safety applications?
A4: Yes, isolated I/O versions provide channel-to-channel protection to reduce electrical interference risks.
Q5: Where is the 3500/60 commonly used?
A5: It is widely used in power plants, substations, chemical plants, steel mills, and industrial automation systems.
| 147663-01 | Process control signal module |
| 149844-01 | Temperature monitoring interface unit |
| 149992-01 | Modular I/O interface board |
| 149992-02 | Modular I/O interface board, upgraded |
| 16710-06 | Control signal relay module |
| 16710-07 | Control signal relay module, version 7 |
| 16710-10 | Control signal relay module, version 10 |
| 16710-12 | Control signal relay module, version 12 |
| 16710-14 | Control signal relay module, version 14 |
| 16710-16 | Control signal relay module, version 16 |
| 16710-50 | Control signal relay module, version 50 |
| 16710-66 | Control signal relay module, version 66 |
| 16925-15 | Analog input signal board |
| 16925-20 | Analog input signal board, version 20 |
| 16925-21 | Analog input signal board, version 21 |
| 16925-99 | Analog input signal board, special |
| 169459-01 | Digital I/O expansion module |
| 170133-090-00 | High-speed communication interface card |
