Product Name:3500/94M VGA Display Monitor
Brand Name:Bently Nevada
Model Number:3500/94M 184826-01
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
3500/94M 184826-01 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Description |
|
Model |
3500/94M-184826-01 |
|
Product Type |
VGA Display Module |
|
System Compatibility |
Bently Nevada 3500 Series |
|
Display Options |
10” / 15” Advantech LCD |
|
Power Consumption |
4.6 W max |
|
Communication |
VGA / RS232 / Ethernet |
|
Operating Temp |
-20°C to +65°C |
|
Storage Temp |
-40°C to +85°C |
|
Humidity |
Up to 95% non-condensing |
|
Mounting Type |
Rack / Panel / Independent |
|
Dimension (Module) |
2.5x25.2x24cm |
|
Weight |
0.78kg |
The 3500/94M-184826-01 — Bently Nevada VGA Display Module is a high-performance industrial visualization unit designed for the 3500 machinery protection system. It provides real-time access to system events, alarm logs, module data, and machinery condition status in a clear graphical interface.
The 3500/94M VGA display system supports multiple custom screen configurations, allowing operators to view vibration trends, proximity gap values, and machine train diagnostics. Integrated with 3500 rack configuration software, it ensures flexible data presentation and improved monitoring efficiency.
Designed for industrial environments, the 3500/94M 184826-01 supports remote display connectivity through KVM extenders and router boxes. It enables stable long-distance visualization while maintaining high signal integrity, making it ideal for centralized monitoring applications in critical industries.
Q1: What system is the 3500/94M compatible with?
A1: It is designed for the Bently Nevada 3500 machinery protection system.
Q2: Can the display be used remotely?
A2: Yes, it supports KVM extenders for long-distance visualization up to kilometers.
Q3: How many custom screens are supported?
A3: Up to nine custom display screens can be configured.
Q4: What types of displays are supported?
A4: It supports Advantech 10-inch and 15-inch industrial touch screens.
Q5: Is it suitable for hazardous environments?
A5: Yes, certain configurations are certified for Class I Division 2 and ATEX areas.
| Number | Description |
|---|---|
| 122M3217 | 3500/94M VGA display monitor datasheet |
| 122M3218 | Operation and maintenance manual for 3500/94M module |
| 184826-01 | 3500/94M main VGA display module |
| 190214-01 | Normal I/O module for 3500/94M system |
| 190214-02 | Power-only I/O module for front-mounted display |
| 120M8155-01 | Advantech 10-inch industrial touch display |
| 122M3368-01 | Face mount kit for 10-inch display |
| 122M4631-AA | Rack mounting standoff kit (EIA 19-inch compatible) |
| 107M3696-01 | Front video/serial/power cable (3 ft) |
| 119M6509-03 | Power supply cable for 10-inch display (3.05 m) |
| 02200794 | 24V DIN rail power supply unit |
| 161087-AA00 | VGA male-to-male display cable |
| 148638-AA | DB-9 communication cable for I/O connection |
