Product Name: 3300 XL 8 mm Probe
Brand Name: Bently Nevada
Model Number: 330104-08-16-10-02-00
Place of Origin: United States
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
overview
| Product Name | 3300 XL 8 mm Probe |
| Brand Name | Bently Nevada |
| Model Number | 330104-08-16-10-02-00 |
| Place of Origin | USA |
| Warranty | 12 months |
| Payment Methods | T/T |
| Shipment | DHL/UPS/EMS/Fedex... |
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
| Product Name | Bently Nevada 330104-08-16-10-02-00 3300 XL 8 mm Probe |
| Manufacturer | Bently Nevada |
| Product Type | 3300 XL 8 mm Probe |
| Part Number | 330104-08-16-10-02-00 |
| Dimensions | 112.2x2x2cm |
| Weight | 0.14kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Condition | New & Original in Factory Packing |
| Power Requires | -17.5 Vdc to -26 Vdc |
| Maximum consumption | -23 Vdc to -26 |
| Output Resistance | 50 Ω |
| Nominal Probe DC Resistance | 7.45 ± 0.50 Ω |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 stainless steel (SST) |
| Probe Cable | 75Ω triaxial, fluoroethylene propylene (FEP) insulated |
| Armor (optional on both) | Flexible AISI 302 or 304 SST with FEP outer jacket |
| Connector Material | Gold-plated brass or gold plated beryllium copper |
| Probe Case Torque | 33.9 N•m (300 in•lbf) (Maximum) |
| Unthreaded Length Option | 80 mm |
| Overall Case Length Option | 160 mm |
| Total Length Option | 1.0 meter (3.3 feet) |
| Connector and Cable-Type Option: | Miniature coaxial ClickLoc connector, standard cable |
| Agency Approval Option | Not required |
The Bently Nevada 330104-08-16-10-02-00 is an 8 mm proximity probe from the 3300 XL series designed for vibration and position monitoring of rotating machinery. It serves as the primary sensing interface between industrial equipment and monitoring systems, converting mechanical motion into precise electrical signals. Built with robust industrial-grade materials, it ensures stable performance in harsh environments and is fully compatible with legacy 3300 series systems.
The Bently Nevada 330104-08-16-10-02-00 belongs to the 3300 XL 8 mm Probe series and features an M10 × 1 metric threaded flush-mount design. It has a total length of 1.0 m (3.3 ft), with an unthreaded length of 80 mm and a case length of 160 mm. The probe operates with a 50 Ω output resistance and a nominal DC resistance of 7.45 ± 0.50 Ω. It is powered by a -17.5 Vdc to -26 Vdc supply and uses a miniature coaxial ClickLoc connector for secure, tool-free installation. The cable is a 75 Ω triaxial type with FEP insulation, ensuring reliable signal integrity. The probe tip is made of polyphenylene sulfide (PPS), while the housing is constructed from AISI 303/304 stainless steel for durability. The unit weighs 0.14 kg and supports a maximum operating torque of 33.9 N·m (300 in·lbf).
High durability
8 mm stainless steel body ensures strong mechanical resistance in industrial environments.
Reliable signal transmission
75 Ω triaxial FEP-insulated cable minimizes signal loss and interference.
Easy installation
ClickLoc connector enables tool-free, secure, and vibration-resistant connection.
Enhanced sensing stability
PPS probe tip provides strong encapsulation and improved thermal/mechanical stability.
Backward compatibility
Works with non-XL 3300 series monitoring systems.
Industrial-grade reliability
Designed for continuous operation in harsh rotating machinery environments.
Turbines (steam, gas, hydro)
Compressors and pumps
Electric motors and generators
Industrial fans and blowers
Gearboxes and rotating shafts
Critical rotating machinery in oil & gas, power generation, and petrochemical plants
The Bently Nevada 330104-08-16-10-02-00 3300 XL 8 mm Probe plays a key role in condition monitoring and machinery protection systems by continuously measuring shaft vibration and position. It enables:
Real-time vibration monitoring for early fault detection
Axial and radial displacement measurement
Early warning of misalignment, imbalance, and mechanical wear
Integration into protection systems to trigger alarms or shutdowns
Improved predictive maintenance strategies by providing stable, high-accuracy signals
