Product Name: Low Frequency Velocity Sensor
Brand Name: Bently Nevada
Model Number: 330505-02-02-02
Place of Origin: United States
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Alternative Names
Low-frequency vibration velocity transducer
Industrial vibration velocity sensor
Vibration velocity monitoring probe
Machinery condition monitoring velocity sensor
Low-frequency vibration measurement sensor
Bently Nevada velocity transducer (330505 series)
The Bently Nevada 330505-02-02-02 Low Frequency Velocity Sensor is to measure and monitor low-frequency vibration velocity in rotating and reciprocating machinery for condition monitoring and predictive maintenance. It converts mechanical vibration into proportional electrical signals, enabling accurate detection of early-stage mechanical issues such as imbalance, misalignment, looseness, or bearing faults. This helps improve equipment reliability, prevent unexpected failures, and support continuous machinery health assessment in industrial environments.
The core parameters of the Bently Nevada 330505-02-02-02 Low Frequency Velocity Sensor include a sensitivity of 20 mV/mm/s (508 mV/in/s) with ±10% tolerance, a frequency response range of 0.5–1000 Hz (±3 dB) and a more precise band of 1–200 Hz (±0.9 dB), a peak velocity measurement capability up to 102 mm/s (4 in/s), and amplitude linearity within ±3% across the operating range. Electrically, it operates with a bias voltage of –12 ±1 VDC, provides insulation resistance of at least 120 MΩ at 500 VDC, and withstands dielectric strength up to 600 VRMS at 50 Hz for 1 minute. Additional characteristics include a low noise floor of 3 µm/s RMS at 100 Hz and a typical cable capacitance of 45 pF/m, ensuring stable and accurate vibration signal transmission in industrial monitoring applications.
The Bently Nevada 330505-02-02-02 Low Frequency Velocity Sensor is a precision industrial vibration monitoring device designed for reliable measurement of low-frequency mechanical vibrations in critical rotating machinery. It features a compact design with a 90° ±5° mounting angle and an M8×1 adapter, allowing easy installation in space-constrained environments while ensuring accurate alignment. Engineered for condition monitoring and predictive maintenance systems, it provides stable and high-sensitivity velocity output signals that support early detection of mechanical faults and help improve equipment reliability. With robust electrical characteristics, a wide operational frequency range, and strong resistance to electrical noise and environmental interference, the sensor delivers consistent performance in demanding industrial applications such as turbines, motors, pumps, and other rotating equipment.
|
Email: |
Whatsapp: |
| Product Name | Bently Nevada 330505-02-02-02 Low Frequency Velocity Sensor |
| Manufacturer | Bently Nevada |
| Product Type | Low Frequency Velocity Sensor |
| Part Number | 330505-02-02-02 |
| Dimensions | 9.5x3.2x3.2cm |
| Weight | 0.34kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Transducer Mounting Angle | -02 - 90° ± 5° |
| Internal Mounting Thread | -02 - 3/8-24 UNF-2B |
| Mounting Adapter Option | -02 - M8 x 1 |
| Sensitivity | 20 mV/mm/s (508 mV/in/s) ±10% |
| Frequency Range | 0.5–1000 Hz (±3 dB); 1–200 Hz (±0.9 dB) |
| Peak Velocity | 102 mm/s (4 in/s) |
| Amplitude Linearity | ±3% ≤102 mm/s |
| Bias Voltage | –12 ±1 VDC |
| Insulation Resistance | ≥120 MΩ @ 500 VDC |
| Dielectric Withstand | 600 VRMS, 50 Hz, 1 min |
| Noise Floor | 3 µm/s RMS @ 100 Hz |
| Cable Capacitance | 45 pF/m typical |
Condition monitoring of rotating machinery such as motors, pumps, compressors, and turbines
Industrial predictive maintenance systems for early fault detection
Low-frequency vibration monitoring in mechanical equipment with slow-speed operation
Power generation plants for turbine and auxiliary system monitoring
Oil and gas facilities for rotating asset health assessment
Manufacturing and process industries requiring continuous machinery diagnostics
High sensitivity low-frequency vibration velocity measurement for accurate condition monitoring
Wide frequency response range of 0.5–1000 Hz with enhanced precision in the low-frequency band
Compact design with 90° ±5° mounting angle for easy installation in confined spaces
M8×1 adapter for flexible and secure mechanical integration
Strong electrical performance with high insulation resistance and dielectric strength
Low noise floor ensuring stable and reliable signal output
Good amplitude linearity up to high vibration levels for consistent measurement accuracy
Designed for harsh industrial environments with stable long-term performance
