Product Name:Seismic Dual Epoxy Relays
Brand Name:Bently Nevada
Model Number:84145-01
Country of Origin:USA
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
84145-01 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Product Model: | 84145-01 seismic dual epoxy relay module, designed for 3300 system seismic monitoring and alarm switching |
| System Compatibility: | Bently Nevada 3300 series rack systems, compatible with seismic dual probe monitoring architecture |
| Relay Type: | Dual epoxy-sealed relays, provides stable switching for alarm and protection signals |
| Input Signal: | Accepts seismic and transducer-based monitoring signals, integrated with system monitor logic |
| Output Function: | Relay switching output, supports alert and danger alarm control signals |
| Operating Voltage: | 24 VDC system supply, stable low-power industrial operation |
| Power Consumption: | Low-power design, optimized for continuous monitoring environments |
| Dimension: | Approx. 83 mm (H) x 50 mm (W) x 120 mm (D), rack-mounted compact structure |
| Weight: | 1.0 kg (2.2 lbs), lightweight module suitable for modular rack installation |
| Mounting Type: | Plug-in rack module, installs directly into 3300 system rack slot |
The 84145-01 is designed as a rugged relay solution for use within Bently Nevada 3300 monitoring systems. It provides reliable switching performance for seismic monitoring applications where stable alarm and protection output is required in demanding industrial environments.
As part of the 3300 series spare relay assemblies, including 84139-01 and 84151-01, this module ensures compatibility with existing rack-based configurations while maintaining consistent system integration and operational stability.
Built for long-term reliability, the 84145-01 is widely used in vibration monitoring systems to support alarm handling, machine protection logic, and condition monitoring tasks in critical rotating machinery applications.
Power plants: Used for generator set condition monitoring, turbine vibration alarm handling, and relay protection logic integration.
Substations (substations): Enable switchyard monitoring, bus protection control, and fault alarm relay output processing.
Chemical plants: Support process automation systems, intrinsic safety signal relay switching, and equipment condition monitoring.
Steel mills (metallurgical plants): Operate reliably in high-temperature and EMI-heavy environments for equipment protection control.
Machinery manufacturing plants: Used in automated production lines, robotics systems, and packaging machine safety control circuits.
Q1: What is 84145-01 used for?
A1: It is used as a seismic dual epoxy relay module for alarm switching in Bently Nevada 3300 monitoring systems.
Q2: Is 84145-01 compatible with other 3300 modules?
A2: Yes, it is fully compatible with standard 3300 rack-based monitoring and relay configurations.
Q3: What type of relays does 84145-01 use?
A3: It uses dual epoxy-sealed relays designed for reliable industrial signal switching.
Q4: Can 84145-01 be used in harsh environments?
A4: Yes, it is designed for high vibration, high temperature, and EMI-heavy industrial environments.
Q5: What is the main function of this module?
A5: Its main function is to provide stable relay output for seismic monitoring alarm and protection systems.
