Model: 176449-02 | Brand: Bently Nevada
Series: 3500/42M | Type: Proximitor Seismic Monitor
Dimensions: 241.3 × 24.4 × 241.8 mm | Weight: 0.91 kg
Email: [email protected] | WhatsApp: +86 18159889985
Bently Nevada 3500/42M
The 176449-02 is a four-channel 3500/42M monitoring module. It accepts signals from compatible proximity, velocity and acceleration transducers, conditions those signals and compares configured measurements with alarm setpoints.
This quotation includes one 176449-02 front 3500/42M monitor module only. Rear I/O modules, transducers, 3500 rack, cables, software and other accessories are not included unless they are listed separately in our quotation.
Send the required quantity, destination country and installed transducer/I/O information. We will confirm the exact quoted scope before order.
Email: [email protected]WhatsApp: +86 18159889985The 3500/42M processes up to four transducer signals. Its channels are programmed in pairs, and the module can perform as many as two supported monitoring functions at one time. Depending on the selected channel configuration and transducers, these functions can include radial vibration, thrust position, eccentricity, differential expansion, acceleration, velocity, shaft absolute and circular acceptance-region monitoring.
| Manufacturer | Bently Nevada |
|---|---|
| Part number | 176449-02 |
| Series / type | 3500/42M Proximitor Seismic Monitor |
| Channels | Four monitor channels, configured in pairs |
| Accepted signal families | Proximity, velocity and acceleration transducers |
| Monitoring functions | Up to two supported function types per module |
| Power consumption | 7.7 W typical |
| System role | Signal conditioning, alarm comparison, system data and relay-support outputs |
The illustration explains compatible front and rear arrangements. It does not mean that any rear I/O module is included with this quotation.
Transducer type, rear I/O termination and channel configuration must match the installed monitoring design. The 176449-02 is the front monitor part number; compatible rear I/O modules are separate items. Provide the existing module and rear-I/O part numbers so the requested configuration can be checked before order.
No. This page is quoted as one 176449-02 front monitor module only. Rear I/O and transducers must be requested separately.
Yes. The gallery shows the currently available unit. The diagrams below are manufacturer reference images for configuration and installation context.
Send photos or part numbers for the front module, rear I/O and installed transducers, together with the required channel functions.
Contact our sales team for current availability, price and lead time.
