Bently Nevada 991-06-XX-01-00 MOD:169955-01 991 Thrust Transmitter, China Bently Nevada 991-06-XX-01-00 MOD:169955-01 991 Thrust Transmitter Manufacturers, Suppliers, Factory

Tag

Bently Nevada 991-06-XX-01-00 MOD:169955-01	2-Wire Thrust Transmitter
991 Thrust Transmitter	DIN Rail Mounted Transmitter
Axial Displacement Transmitter	35 mm DIN Rail Sensor Device
Bipolar Thrust Monitoring Sensor	Proximity Probe Signal Conditioner
±0.6 mm Range Transmitter	3300 NSv Compatible Transmitter
OEM Machinery Monitoring Device	Cost-Effective Condition Monitoring Device
Pump Axial Position Sensor	Small Rotating Machinery Sensor
Motor Thrust Monitoring Sensor	Turbomachinery OEM Sensor
Fan Shaft Position Transmitter	Industrial Control Signal Device
Industrial 4–20 mA Loop Powered Transmitter	Non-Hazardous Area Monitoring Instrument

Description

The Bently Nevada 991-06-XX-01-00 MOD:169955-01 991 Thrust Transmitter is a compact, cost-effective axial displacement monitoring device designed for OEM rotating machinery such as pumps, motors, compressors, and fans. It converts input from a 3300 NSv proximity probe system into a proportional 4–20 mA output signal, representing bipolar shaft movement within a ±0.6 mm measurement range.

The Bently Nevada 991-06-XX-01-00 MOD:169955-01 991 Thrust Transmitter is specifically optimized for small axial displacement applications where precise but economical monitoring is required. Its DIN rail mounting and loop-powered 2-wire design make it easy to install in control panels, while eliminating the need for complex wiring or external power supplies.

Functions

Measures small axial displacement (thrust) in rotating machinery
Converts probe input into a bipolar 4–20 mA output signal
Provides real-time shaft position monitoring and trending
Supports basic machine protection and alarm logic in OEM systems
Interfaces with 3300 NSv proximity probe systems
Enables cost-effective condition monitoring for small rotating equipment
Assists in detecting early bearing wear or thrust imbalance

Get in Touch

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Winnie
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Specifications

Product Name	Bently Nevada 991-06-XX-01-00 MOD:169955-01 991 Thrust Transmitter
Manufacturer	Bently Nevada
Product Type	991 Thrust Transmitter
Part Number	991-06-XX-01-00 MOD:169955-01
Dimensions	10x7.4x5.8cm
Weight	0.5 kg
Place of shipment	Xiamen, China
Country of origin	USA
Full-Scale Range	0.6-0-0.6 mm (±0.6 mm)
Mounting	35 mm DIN rail clips
Power Supply	Two-wire, loop-powered
Output Signal	Proportional 4-20 mA (axial displacement)
Input Source	3300 NSv proximity probe with extension cable (5 m or 7 m options)
Agency Approval	Not required
Key Benefit	Solves the pain point of cost-effective axial position monitoring for OEM equipment—0.6-0-0.6 mm bipolar range matches typical thrust movement in small rotating machinery, with simple 4-20 mA output and no agency approvals required
System Length Option	5.0 meters / 7.0 meters

Key Features

Bently Nevada 991-06-XX-01-00 MOD:169955-01 991 Thrust Transmitter designed for OEM machinery applications
Bipolar measurement range: 0.6–0–0.6 mm (±0.6 mm)
4–20 mA output proportional to axial displacement (centered at 12 mA neutral point)
Two-wire loop-powered design for simplified wiring and installation
DIN rail mounting (35 mm standard) for easy panel integration
Compatible with Bently Nevada 991-06-XX-01-00 MOD:169955-01 991 Thrust Transmitter and 3300 NSv proximity probe systems
Supports 5 m and 7 m system length configurations
No agency approvals required for non-hazardous industrial environments
Compact and cost-effective solution for OEM equipment monitoring
Simple installation with reduced hardware and labor cost
Reliable axial position tracking for small rotating machinery

FAQ

Q1: What is the measurement range of Bently Nevada 991-06-XX-01-00 MOD:169955-01?
A: The 991-06-XX-01-00 MOD:169955-01 has a bipolar full-scale range of ±0.6 mm (0.6–0–0.6 mm).

Q2: What output signal does Bently Nevada 991-06-XX-01-00 MOD:169955-01?
A: The 991-06-XX-01-00 MOD:169955-01 provides a proportional 4–20 mA output signal centered at 12 mA for neutral position.

Q3: How is 991-06-XX-01-00 MOD:169955-01 991 installed?
A: The 991-06-XX-01-00 MOD:169955-01 Transmitter is installed using a 35 mm DIN rail mounting system for quick and easy panel integration.

Q4: What type of probe does 991-06-XX-01-00 MOD:169955-01 991 Thrust Transmitter use?
A: The 991-06-XX-01-00 MOD:169955-01 uses input from 3300 NSv proximity probes with 5 m or 7 m extension cable options.

Q5: What is the key advantage of 991-06-XX-01-00 MOD:169955-01?
A: The 991-06-XX-01-00 MOD:169955-01 provides a low-cost, simple, and reliable solution for axial position monitoring without requiring complex monitoring systems or agency approvals.
