Product Name:3300 XL 8 mm Proximity Probes
Brand Name:BENTLY NEVADA
Model Number:330101-00-16-10-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330101-00-16-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Specification |
|---|---|
| Model | 330101-00-16-10-02-00 |
| System Type | 3300 XL 8 mm Proximity Probe |
| Thread Type | 3/8-24 UNF |
| Probe Length | 0.5 m – 9.0 m configurable |
| Output Signal | Eddy current proportional voltage |
| Operating Temp | -52°C to +177°C |
| Storage Temp | -52°C to +177°C |
| Cable Type | 75Ω triaxial FEP insulated |
| Connector Type | Gold-plated ClickLoc |
| Minimum Bend Radius | 25.4 mm (1.0 in) |
| Weight | 0.06kg |
| Dimension | 112x1.5x1.2cm |
The330101-00-16-10-02-00is part of the Bently Nevada 3300 XL 8 mm proximity probe series, engineered for high-precision vibration and position monitoring in industrial machinery. Built as part of the3300 XL 8 mm system, it works seamlessly with compatible extension cables and Proximitor sensors to deliver stable and accurate eddy current measurement performance.
The system is designed for turbine machinery, compressors, and fluid-film bearing equipment, ensuring reliable signal output under harsh operating conditions. With advanced ClickLoc connectors and reinforced probe construction, it supports secure installation and long-term stability.
As a key component in the3300 XL 8 mm family, including probes such as330102and330130, this model ensures interchangeability, improved RFI immunity, and consistent measurement accuracy across demanding industrial environments.
Q1: What is the 330101-00-16-10-02-00 used for?
A1: It is used for vibration, displacement, and shaft position monitoring in rotating machinery systems.
Q2: Can it work with other 3300 XL components?
A2: Yes, it is fully compatible with 3300 XL extension cables and Proximitor sensors.
Q3: Is it suitable for harsh industrial environments?
A3: Yes, it is designed for high temperature, vibration, and EMI-heavy environments.
Q4: Does it support different cable lengths?
A4: Yes, multiple cable length options are available depending on installation needs.
Q5: What industries commonly use this probe?
A5: It is widely used in power plants, compressors, chemical plants, and steel manufacturing systems.
| Number | Description |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual |
| 175751 | 3300 XL Multi-Purpose Stainless Steel Housing, 12”x12”x6”, supports up to 8 DIN-mount or 6 panel-mount Proximitor sensors, ATEX Zone 0/1 certified |
| 176467 | 3300 XL Multi-Purpose Stainless Steel Housing, 12”x8”x6”, supports up to 4 Proximitor sensors, DIN/panel mount, ATEX Zone 0/1 certified |
| 330181 | 3300 XL Stainless Steel Housing, 13”x9.5”x7”, supports up to 8 DIN or 6 panel sensors, hazardous area approvals (ATEX Zone 0/1, North American Division 1/2) |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, length specified in feet |
| 138492-01 | Replacement panel-mount mounting pad |
| 138493-01 | Replacement DIN-mount mounting pad |
| 148722-01 | 3300 XL test plug with 3 test pins, 1-meter color-coded wires and banana plugs, used for Proximitor sensor testing without removing field wiring |
| 04310310 | 3300 XL Proximitor sensor panel-mount screw, 6-32 UNC thread forming screw (4 required per sensor) |
| 03200006 | Silicone self-fusing tape, 9.1 m roll for connector insulation and environmental protection |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables including installation tools |
| 136536-01 | Connector protector adapter for compatibility with pre-1998 installation tools and 75Ω ClickLoc connectors |
| 40180-02 | Connector protectors, package of 10 pairs for 3300 XL 8 mm probes and cables |
| 03839410 | 75Ω triaxial male connector protector for extension cable environmental protection |
| 03839420 | 75Ω triaxial female connector protector for probe lead and Proximitor sensor connection protection |
| 04301007 | 3/8-24 probe lock nut with safety wire holes for secure probe fixation |
| 04301008 | M10 x 1 probe lock nut with safety wire holes for secure installation |
| 330153-01 | 3300 XL connector kit including male/female ClickLoc connectors, sleeves, tubing, and silicone tape |
