Product Name: 16-Channel Output Relay Module
Brand Name: EMERSON
Model Number: A6500-RC
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | EMERSON A6500-RC 16-Channel Output Relay Module |
| Manufacturer | EMERSON |
| Product Type | 16-Channel Output Relay Module |
| Part Number | A6500-RC |
| Estimated shipping dimensions | 5x19x12.7cm |
| Weight | 0.42kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Number of Inputs | 66 |
| Logic Low Leve | 0V to 3V |
| Logic High Level | 13V to 32V |
| Rated Current | 1 mA |
| Rated Power | 24 mW |
| Number of Outputs | 16 |
| Type | SPDT |
| Maximum Voltage Capacity | 32V DC / 48V AC |
| Rated Current | 2 A |
| Rated Power | 96 W |
The EMERSON A6500-RC is a high-performance industrial relay module designed for signal processing, alarm handling, and control integration within automation and machinery protection systems. It provides reliable input monitoring and output switching functions, making it suitable for complex industrial control applications that require stable and efficient signal management.
The module features 66 digital inputs and 16 SPDT relay outputs, enabling flexible signal acquisition and control operation. It supports logic low levels from 0V to 3V and logic high levels from 13V to 32V, ensuring compatibility with a wide range of industrial control signals. The relay outputs support up to 32V DC or 48V AC with a rated switching current of 2 A, allowing dependable control of external devices and alarm circuits.
Designed for industrial environments, the A6500-RC offers compact installation, stable electrical performance, and reliable relay operation for continuous system monitoring and control tasks. Its robust design makes it suitable for integration into critical machinery monitoring and automation architectures.
High Input Capacity
The EMERSON A6500-RC supports 66 digital inputs, enabling efficient management of multiple monitoring and control signals within a single module.
Flexible Relay Output Design
With 16 SPDT relay outputs, the module provides versatile switching capability for alarms, interlocks, and external control devices.
Wide Signal Compatibility
The module supports logic low levels from 0V to 3V and logic high levels from 13V to 32V, ensuring compatibility with various industrial systems.
Reliable Switching Performance
Relay outputs support up to 32V DC / 48V AC and 2 A current capacity, enabling dependable operation in demanding industrial applications.
Compact and Efficient Integration
Its compact structure simplifies installation in control cabinets while reducing overall system wiring complexity.
Industrial-Grade Reliability
The robust design ensures stable long-term operation in continuous industrial monitoring and automation environments.
The EMERSON A6500-RC delivers stable and efficient signal management performance for industrial automation and machinery protection systems. Its 66 digital input channels allow simultaneous monitoring of multiple process signals, while the 16 SPDT relay outputs provide reliable switching for alarms, interlocks, and external device control.
The module supports a wide input logic range, with logic low levels from 0V to 3V and logic high levels from 13V to 32V, ensuring stable compatibility with industrial control systems. Its relay outputs are rated for up to 32V DC or 48V AC with a switching current capacity of 2 A, enabling dependable performance under continuous operating conditions.
Designed for operational efficiency, the A6500-RC reduces system complexity by combining high-density input monitoring and relay output control within a single compact module. This integrated design minimizes wiring requirements, improves maintenance efficiency, and enhances overall system reliability in critical industrial applications.
1. What is the relay switching capacity of the A6500-RC?
The A6500-RC supports up to 32V DC / 48V AC with a rated switching current of 2 A.
2. How many inputs does the A6500-RC support?
The A6500-RC supports 66 digital input channels.
3. What type of outputs does the A6500-RC provide?
The A6500-RC provides 16 SPDT relay outputs for switching and control applications.
4. What voltage levels are supported by the A6500-RC inputs?
The A6500-RC supports logic low levels from 0V to 3V and logic high levels from 13V to 32V.
5. Where is the A6500-RC commonly used?
The A6500-RC is commonly used in machinery monitoring, process automation, and industrial protection systems.
6. How does the A6500-RC improve system efficiency?
The A6500-RC combines high-density input monitoring and relay control into one compact module, reducing wiring complexity and installation space.
