Product Name: Analog Input Module
Brand Name: EMERSON Westinghouse
Model Number: 1C31116G01
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Westinghouse |
Model Number: |
1C31116G01 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Description |
Value |
|
Model |
1C31116G01 |
|
Channels |
8 analog inputs |
|
Input Range |
4–20 mA, ±1V, ±5V, ±10V, ±20mV to ±250mV |
|
Resolution |
14-bit (including polarity) |
|
Accuracy |
±0.10% full scale |
|
Sampling Rate |
16/20 samples per second (50/60 Hz) |
|
Dimension |
120 × 80 × 40 mm |
|
Weight |
0.3 kg |
|
Input Impedance |
up to 200 MΩ |
|
Isolation |
1000 V AC/DC (channel-to-channel & logic) |
|
Power Consumption |
2.4 W typical, 3.125 W max |
1C31116G01 — high-speed analog input personality module designed for Ovation systems, supporting precise multi-signal acquisition with strong noise immunity, flexible wiring, and reliable industrial process monitoring performance.
Q1: What signals does the 1C31116G01 support?
A1: It supports current and voltage signals including 4–20 mA and ±10V ranges.
Q2: How many channels are available?
A2: The module provides 8 independent analog input channels.
Q3: Does it support noise protection?
A3: Yes, it features high common-mode and normal-mode rejection.
Q4: What is the sampling rate?
A4: It supports 16 or 20 samples per second depending on frequency configuration.
Q5: Is it suitable for harsh environments?
A5: Yes, it is designed for industrial environments with strong EMI resistance.
