Product Name: Eddy Current Signal Converter
Brand Name: Emerson
Model Number: PR6423/009-031 CON041
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Tag
| Emerson PR6423 Converter | High-Speed Signal Converter |
| Vibration Monitoring Module | Predictive Maintenance Device |
| Displacement Signal Converter | Industrial Automation Module |
| Industrial Signal Conditioner | DIN Rail Signal Converter |
| Turbomachinery Monitoring | Real-Time Condition Monitoring |
| Shaft Vibration Monitoring | Rotating Machinery Protection |
| Dynamic Displacement Measurement | Industrial Vibration Monitoring |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | Emerson PR6423/009-031 CON041 Eddy Current Signal Converter |
| Manufacturer | Emerson |
| Product Type | Eddy Current Signal Converter |
| Part Number | PR6423/009-031 CON041 |
| Weight | 0.28kg |
| Estimated shipping dimensions | 20x20x2cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Frequency Range (-3 dB) | 0 to 20,000 Hz |
| Rise Time | <15µs |
| Operating Temperature Range | -30 to 100°C (-22 to 212°F) |
| Shock and Vibration | 5g @ 60Hz @ 25°C (77°F) |
| Protection Class | IP20 |
| Supply Voltage Range | -23V to -32V (Output Range -4V to -20V); -21V to -32V (Output Range -2V to -18V) |
| Housing Material / Weight | PA 6.6 / ~60 grams (2.12 oz) |
| Mounting | Din Rail |
| Connections | Screw Terminal (Max. 1.5mm2,Wire-end Sleeves) |
| Measuring Range | 2.0mm (Standard Range) |
| Linearity Error | ≤ 1.0% |
The Emerson PR6423/009-031 CON041 Eddy Current Signal Converter is a high-performance conversion module designed for high-speed vibration and displacement monitoring in industrial rotating machinery. It provides precise signal amplification and conversion for eddy current probes, making it ideal for condition monitoring and machinery protection systems.
With a frequency response range of 0 to 20,000 Hz and a rise time of less than 15 µs, the converter accurately captures rapid dynamic changes in turbines, compressors, pumps, and fans. It delivers stable and reliable monitoring performance with a linearity error of ≤1%, ensuring accurate vibration and displacement measurement.
The converter supports a wide supply voltage range and features a lightweight yet durable PA 6.6 housing with IP20 protection. Designed for DIN rail mounting and screw terminal connections, it allows easy installation and maintenance in industrial control cabinets. The Emerson PR6423/009-031 CON041 is a dependable solution for predictive maintenance and continuous machinery health monitoring applications.
Mechanical Configuration
The converter features a lightweight PA 6.6 housing with DIN rail mounting for easy installation inside industrial control cabinets. Screw terminal connections support convenient and secure field wiring.
Electrical Configuration
The device supports a frequency range of 0–20,000 Hz with a rise time below 15 µs for accurate high-speed signal processing. It operates with supply voltages from -23V to -32V and provides stable output conversion with ≤1% linearity error.
Environmental Configuration
The converter operates within temperatures from -30°C to 100°C and withstands vibration levels of 5g @ 60Hz @ 25°C. Its IP20 protection rating supports reliable indoor industrial operation.
System Integration Configuration
The PR6423/009-031 CON041 integrates with eddy current probes and machinery monitoring systems for continuous vibration and displacement monitoring in turbines, compressors, pumps, and fans.
Programming & Monitoring Functions
The converter supports predictive maintenance and machinery protection systems by delivering stable real-time monitoring signals for vibration, displacement, and dynamic equipment condition analysis.
