Parameter Details

Product Name	Emerson PR6424/013-110 CON021 Eddy Current Sensor
Manufacturer	Emerson
Product Type	Eddy Current Sensor
Part Number	PR6424/013-110 CON021
Weight	0.5kg
Estimated shipping dimensions	23x20x4cm
Place of shipment	Xiamen, China
Country of origin	Germany
Sleeve Thread	0 = M18x1.5
Armored Cable	1 = WITH
Total Sensor Length (C=Cx +12.5mm)	3 = 82.5 mm
Adaptor Plug	1 = WITHOUT
Total Cable Length	1 = 5 m
Cable End	0 = LEMO
Sensitivity/Linearity	4 V/mm (101.6 mV/mil) ≤ ±1.5
Air Gap (Center)	Approx. 2.7 mm (0.11”) Nominal
Long Term Drift	< 0.3%
Target/Surface Material	Ferromagnetic Steel (42 Cr Mo4 Standard)
Maximum Surface Speed	2,500 m/s (98,425 ips)
Shaft Diameter	≥80mm
Material	Sleeve – Stainless Steel, Cable – PTFE
Operating Temperature Range	-35 to 150°C (-31 to 302°F)
Temperature Error	<4%/100°K (API 670 Compliant)
Pressure Resistance to Sensor Head	10,000 hPa (145 psi)
Shock and Vibration	5g @ 60Hz @ 25°C (77°F)

Brief Explanation

The Emerson PR6424/013-110 CON021 16mm Eddy Current Sensor is a high-precision non-contact displacement sensor designed for critical turbomachinery monitoring applications. It is widely used in steam turbines, gas turbines, hydro turbines, compressors, pumps, and fans to monitor shaft vibration, displacement, position, eccentricity, and speed/key signals.

Engineered for harsh industrial environments, the sensor features a stainless steel sleeve, PTFE armored cable, and excellent resistance to temperature, vibration, and pressure. It delivers stable and accurate measurement performance with 4 V/mm sensitivity, ≤ ±1.5% linearity, and long-term drift below 0.3%.

The Emerson PR6424/013-110 CON021 Eddy Current Sensor supports ferromagnetic steel targets and operates reliably at shaft surface speeds up to 2,500 m/s. With an operating temperature range of -35°C to 150°C and API 670-compliant temperature stability, it is ideal for continuous condition monitoring and predictive maintenance systems in demanding industrial facilities.

Functions

Measures radial and axial shaft displacement
Monitors shaft vibration and dynamic movement
Detects shaft eccentricity and position changes
Provides speed/key signal monitoring
Supports predictive maintenance and condition monitoring
Enables real-time non-contact measurement in rotating machinery
Helps detect early mechanical faults in turbomachinery systems
Improves operational reliability and equipment protection

Features

Advanced non-contact eddy current sensing technology for accurate shaft monitoring
Designed for critical turbomachinery applications including turbines, compressors, pumps, and fans
High measurement sensitivity of 4 V/mm (101.6 mV/mil) for precise displacement detection
Excellent linearity performance with ≤ ±1.5% measurement deviation
Low long-term drift below 0.3% for reliable continuous operation
Supports radial shaft displacement, axial position, eccentricity, and vibration monitoring
Capable of speed/key measurement for rotating machinery diagnostics
Optimized for ferromagnetic steel targets such as 42 Cr Mo4 material
Stable operation with nominal 2.7 mm air gap clearance
Handles shaft surface speeds up to 2,500 m/s in high-speed machinery environments
Durable stainless steel sleeve construction for enhanced mechanical strength
PTFE armored cable design provides excellent wear, heat, and chemical resistance
Wide operating temperature range from -35°C to 150°C
API 670-compliant temperature stability performance
High resistance to industrial shock and vibration conditions
Pressure-resistant design up to 10,000 hPa (145 psi)
Compact M18x1.5 threaded design for easy installation and integration
5-meter cable length supports flexible industrial installation requirements
Reliable signal transmission with LEMO cable termination
Ideal for predictive maintenance and continuous condition monitoring systems

Configuration & Programming

Mechanical Configuration

The sensor features an M18x1.5 threaded sleeve, 82.5 mm total length, armored PTFE cable, and LEMO connector for secure and reliable industrial installation. Its 5 m cable supports flexible equipment integration.

Electrical Configuration

The sensor uses non-contact eddy current technology with 4 V/mm sensitivity and ≤ ±1.5% linearity for accurate shaft displacement and vibration monitoring. It operates with an approximate 2.7 mm nominal air gap.

Environmental Configuration

Designed for harsh industrial environments, the sensor operates from -35°C to 150°C and withstands pressure up to 10,000 hPa and vibration levels of 5g @ 60Hz.

System Integration Configuration

The sensor integrates with turbomachinery monitoring and protection systems for real-time measurement of shaft displacement, eccentricity, vibration, and speed/key signals.

Programming & Monitoring Functions

The sensor supports predictive maintenance and continuous condition monitoring by providing stable real-time data for detecting imbalance, misalignment, and other rotating machinery faults.
