Product Status: Brand new in stock
Part Number: BENTLY NEVADA 330525-00
Origin: U.S.A
Sales Manager: Stella
Email: [email protected]
Phone (WhatsApp): +86 18159889985
Wechat: zxd18159889985
-- Velomitor XA piezo-velocity sensor for industrial vibration monitoring
-- Rugged 316L stainless steel housing for harsh environments
-- Weatherproof connector enabling direct installation without external housing
-- Wide frequency response suitable for rotating machinery diagnostics
-- High shock resistance for reliable operation in heavy-duty equipment
-- Long cable capability for flexible installation in large facilities
The Bently Nevada 330525-00 is a Velomitor XA piezo-velocity sensor designed for vibration monitoring in industrial rotating equipment. It features a rugged 316L stainless steel housing and a hermetically sealed 2-pin connector that allows direct mounting without a separate protective enclosure. The sensor provides a sensitivity of 3.94 mV/mm/s and operates across a frequency range of 4.5 Hz to 2 kHz. Designed for demanding environments, it supports long cable runs and delivers reliable vibration measurements for turbines, compressors, motors, and other critical machinery.
-- Industrial vibration monitoring for motors and pumps
-- Condition monitoring of turbines and compressors
-- Machinery protection systems in power plants
-- Oil & gas equipment monitoring in harsh environments
-- Predictive maintenance programs for rotating equipment
| Feature | Details |
| Model | 330525-00 |
| Product Type | Velomitor XA Piezo-velocity Sensor |
| Sensitivity | 3.94 mV/mm/s (100 mV/in/s) ±5% |
| Frequency Response | 4.5 Hz to 2 kHz (±3 dB) |
| Velocity Range | 1270 mm/s (50 in/s) peak |
| Amplitude Linearity | ±2% to 152 mm/s (6 in/s) |
| Power Requirements | -22 to -30 VDC |
| Bias Current | 2.5 to 6.0 mA |
| Operating Temp | -55°C to +121°C |
| Shock Survivability | 5,000 g peak |
| Housing Material | 316L Stainless Steel |
| Connector | 2-pin Mil-C-26482 |
| Mounting | 1/4-18 NPT thread |
| Weight | ~0.25 kg |
