Product Status: Brand new in stock
Part Number: BENTLY NEVADA 330180-91-05
Origin: U.S.A
Sales Manager: Stella
Email: [email protected]
Phone (WhatsApp): +86 18159889985
Wechat: zxd18159889985
-- 3300 XL Proximitor Sensor for vibration and shaft position monitoring
-- Designed for a 9.0 m total system length configuration
-- DIN rail mounting for flexible installation
-- Compatible with 3300 XL proximity probe systems
-- Stable signal conversion with high measurement accuracy
-- Certified for hazardous environments with multiple approvals
The Bently Nevada 330180-91-05 is a 3300 XL Proximitor Sensor used in vibration and displacement monitoring systems for rotating machinery. The -91 configuration specifies a total system length of 9.0 meters with DIN rail mounting, while the -05 option provides multiple agency approvals including CSA, ATEX, and IECEx for hazardous area applications. The sensor operates from -17.5 Vdc to -26 Vdc and delivers a stable output signal with 50 Ω resistance. It must be paired with a proximity probe and extension cable that together equal a 9.0 m electrical length for proper calibration and measurement accuracy.
-- Turbine vibration monitoring systems
-- Shaft displacement measurement in compressors
-- Hazardous area machinery protection systems
-- Power generation and oil & gas equipment monitoring
-- Industrial predictive maintenance programs
| Feature | Details |
| Model | 330180-91-05 |
| Product Type | 3300 XL Proximitor Sensor |
| System Length | 9.0 meters (29.5 ft) |
| Mounting | DIN rail mounting |
| Power Requirements | -17.5 Vdc to -26 Vdc |
| Output Resistance | 50 Ω |
| Linear Range | 2.0 mm (80 mils) |
| Scale Factor | 7.87 V/mm (200 mV/mil) ±5% |
| Operating Temp | -51°C to +100°C |
| Storage Temp | -51°C to +105°C |
| Hazardous Area Rating | Ex ia IIC T4/T5 Ga |
| Housing Material | A308 / A380 Aluminum |
| Weight | ~0.25 kg |
