Product Name: Personality Module or Cavity Insert
Brand Name: EMERSON Westinghouse
Model Number:1C31238H01
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Westinghouse |
Model Number: |
1C31238H01 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Specification |
|
Part Number |
1C31238H01 |
|
Product Type |
Personality Module Filler / Foam Insert (Cavity Insert) |
|
Manufacturer |
Emerson (Westinghouse) |
|
System Compatibility |
Ovation Distributed Control System (DCS) – Compact I/O Series |
|
Construction |
Non-conductive rigid foam / composite material |
|
Compatible Electronics Modules |
1C31234G01, 1C31232G01, 1C31232G02, 1C31232G03, 1C31233G01, 1C31233G02, 1C31233G03, 1C31233G04 |
|
Electrical Function |
None (passive, non-electronic component) |
|
Primary Role |
Mechanical stabilization, environmental sealing, wiring documentation |
|
Wiring Documentation |
Printed terminal key / wiring schematic label on face |
|
CE Mark Applicability |
CE Mark certified (when used in certified configurations) |
The 1C31238H01 is a passive foam insert engineered for Emerson's Ovation Compact I/O architecture, serving as a mechanical placeholder when an active Personality Module (PMOD) is not required. This 1C31238H01 cavity insert occupies the vacant PMOD slot in the standard Ovation I/O base unit, providing essential lateral support for the Electronics Module (EMOD) above it and sealing the open cavity against environmental contaminants. The 1C31238H01 features a printed wiring schematic label on its face, delivering immediate visual reference for field technicians during installation and maintenance. Constructed from non-conductive, chemically resistant rigid foam, the 1C31238H01 ensures long-term structural integrity without outgassing or degradation within sealed control cabinet environments.
Mechanical Integrity Without Electronics – Eliminates the cost and complexity of an active PMOD while maintaining structural stability and environmental sealing
Tool-Free Installation – Slides directly into the standard PMOD cavity without requiring hardware, special tools, or configuration
Integrated Wiring Documentation – Printed terminal key on the insert face provides immediate visual reference, reducing commissioning errors and eliminating the need for separate wiring diagrams
Vibration and Thermal Resilience – Prevents EMOD flexing and cantilevering under vibration loads common in turbine halls and compressor stations
CE Mark Certified – Fully compliant when used in CE Mark certified Ovation configurations
Decades-Long Service Life – Non-outgassing, chemically resistant material ensures stability within sealed cabinet environments over extended operational periods
Passive Mechanical Filler – Non-electronic, non-conductive rigid foam construction with zero power consumption
Standard PMOD Slot Compatibility – Fits seamlessly into the Personality module position of any standard Ovation I/O base unit
Integrated Wiring Schematic – Printed terminal key documentation on the insert face for immediate field reference
Environmental Sealing – Seals the vacant PMOD cavity against dust, moisture, and airborne contaminants
EMOD Support Structure – Provides lateral stabilization for the Electronics Module, preventing mechanical stress on backplane connectors
Lightweight Passive Component – Sub-0.1 kg weight with no moving parts or active circuitry
Chemical and Thermal Resistance – Non-outgassing material suitable for decades of service in sealed industrial environments
PMOD Slot Occupancy – Fills the Personality module cavity in Ovation I/O base units when an active PMOD is not required, maintaining the physical integrity of the module carrier
Mechanical Stabilization – Provides lateral support for the Electronics Module, preventing flexing and cantilevering under vibration and thermal cycling
Environmental Sealing – Seals the vacant PMOD cavity against dust, moisture, and airborne contaminants
Wiring Documentation – Displays printed terminal key and wiring schematic information for the associated Compact I/O module
Structural Rigidity – Ensures the Compact I/O architecture maintains its mechanical integrity even when the full electronic PMOD is not utilized
Q1: What is the 1C31238H01 and what does it do?
The 1C31238H01 is a passive foam cavity insert that fills the Personality Module (PMOD) slot in Ovation Compact I/O base units when an active PMOD is not required. It provides mechanical stabilization for the Electronics Module, seals the open cavity against environmental contaminants, and displays wiring documentation for field reference.
Q2: Which modules require the 1C31238H01 cavity insert?
The 1C31238H01 is used with Compact I/O Electronics Modules that operate without an active PMOD, including the 1C31234G01 (Compact Contact Input), 1C31232G01/02/03 (Compact Digital Input), and 1C31233G01/02/03/04 (Compact Sequence of Events).
Q3: Is the 1C31238H01 an electronic component?
No. The 1C31238H01 is a strictly passive, non-electronic component constructed from rigid industrial foam. It performs no signal processing or electrical function—its sole purpose is mechanical stabilization, environmental sealing, and wiring documentation.
Q4: Is the 1C31238H01 CE Mark certified?
Yes. The 1C31238H01 cavity insert is CE Mark certified when used in CE Mark certified Ovation configurations.
Q5: Does the 1C31238H01 require any configuration or software setup?
No. The 1C31238H01 is a mechanical placeholder with no active electronics, requiring zero configuration, software setup, or maintenance. It simply slides into the PMOD cavity and remains in place throughout the system lifecycle.
