Product Name: Field Device System Integrator（FDSI） Module
Brand Name: FOXBORO
Model Number: FBM230 P0926GU
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
| Product Name | FOXBORO FBM230 P0926GU Field Device System Integrator（FDSI） Module |
| Manufacturer | FOXBORO |
| Product Type | Field Device System Integrator（FDSI） Module |
| Part Number | FBM230 P0926GU |
| Weight | 0.36kg |
| Estimated shipping dimensions | 4.5x11x11.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| System | Foxboro I/A Series / Standard 200 Series |
| Communication Interfaces | RS-232, RS-422, RS-485 |
| Number of Serial I/O Ports | 4 |
| Port Isolation | Each communication port isolated from single-loop port devices |
| Communication Type | Asynchronous communication; direct connect link for RS-232 |
| Transmission Rates | 300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 baud |
| Communication Protocol | 8-bit characters; odd, even, or no parity; 1 or 2 stop bits |
| I/O Capacity | Up to 64 devices per FBM230; up to 2000 DCI connections |
| Data Types Transferred | 2-byte or 4-byte signed/unsigned integers; 4-byte IEEE single-precision floating-point values; binary values |
| Fastest Allowed ECB Block Period | 500 ms |
| Channel Isolation | Galvanically isolated and referenced to earth (ground) |
| Channel Isolation Withstand | 600 V AC for 1 minute between either channel and earth |
| Input Voltage | 24 V DC +5%, -10% (redundant) |
| Power Consumption | 7 W maximum |
| Heat Dissipation | 7 W maximum |
| Operating Temperature | -20 to +70°C (-4 to +158°F) |
| Operating Relative Humidity | 5–95%, noncondensing |
| Storage Temperature | -40 to +70°C (-40 to +158°F) |
| Storage Relative Humidity | 5–95%, noncondensing |
| Termination Cable Type | Type 5 |
| ESD Immunity | IEC 61000-4-2; 4 kV contact, 8 kV air |
| Radiated Field Immunity | IEC 61000-4-3; 10 V/m at 80–1000 MHz |
| EFT/Burst Immunity | IEC 61000-4-4; 2 kV on I/O, DC power and communication lines |
| Surge Immunity | IEC 61000-4-5; 2 kV on AC/DC power lines; 1 kV on I/O and communications lines |
| Conducted RF Immunity | IEC 61000-4-6; 10 V rms, 150 kHz–80 MHz |
| Power Frequency Magnetic Field Immunity | IEC 61000-4-8; 30 A/m at 50 and 60 Hz |
|
Sales |
|
Phone/Whatsapp |
|
Jim Pei |
The FOXBORO FBM230 P0926GU Field Device System Integrator (FDSI) Module is a versatile serial communication interface designed for Foxboro I/A Series / Standard 200 Series control systems. It provides four isolated serial I/O ports supporting RS-232, RS-422, and RS-485 communication, with configurable transmission rates up to 115200 baud. The module enables integration of intelligent field instruments and third-party devices with the Foxboro control system, allowing reliable exchange of process data, equipment status, and control information. Its flexible communication capability and isolated channel design make it well suited for expanding connectivity and simplifying device integration in industrial process automation systems.
The FOXBORO FBM230 P0926GU is designed to integrate serial field devices and external equipment into Foxboro I/A Series control architectures. It can interface with devices such as analyzers, weighing systems, variable frequency drives, intelligent transmitters, power monitoring equipment, packaged control units, and other instruments using compatible RS-232, RS-422, or RS-485 communications. Its multiple serial ports make it particularly useful where several independent device networks or communication links need to be consolidated into the DCS.
The module is well suited for oil and gas, refining, chemical and petrochemical processing, power generation, water and wastewater treatment, pulp and paper, and other process industries. By providing a communication bridge between third-party serial equipment and the Foxboro control system, the FBM230 supports centralized process monitoring, data acquisition, equipment status reporting, and supervisory control while reducing the need for separate communication gateways.
