Product Name:3300 XL 8 mm Proximity Probes
Brand Name:BENTLY NEVADA
Model Number:330104-00-22-10-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330104-00-22-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Specification |
|
Product Model |
330104-00-22-10-02-00 |
|
Series |
3300 XL 8 mm Proximity Probe |
|
Thread Type |
M10 × 1 metric thread |
|
Cable Type |
Armored triaxial cable |
|
Connector Type |
ClickLoc miniature coaxial |
|
Weight |
0.18kg |
|
Probe Material |
Stainless steel (AISI 303/304) |
|
Cable Resistance |
~7.5–9.9 Ω range (by length) |
|
Operating Temp |
-52°C to +177°C |
|
Storage Temp |
-52°C to +177°C |
|
Mounting Style |
Forward / reverse mount compatible |
|
Dimension |
2x112x1.6cm |
The 330104-00-22-10-02-00 is a high-performance 3300 XL 8 mm proximity probe designed for precise vibration and position measurement in industrial rotating machinery. Built with a rugged M10 × 1 threaded structure and armored cable protection, it ensures stable signal transmission even in harsh operating environments. Integrated within the Bently Nevada 3300 XL system, this probe delivers accurate non-contact sensing for critical monitoring applications such as turbines, compressors, and pumps.
Compared with traditional designs, the 330104-00-22-10-02-00 provides enhanced mechanical durability and improved environmental resistance. Its ClickLoc connector system supports fast installation and secure locking without special tools.
Engineered for interchangeability within the 3300 XL series, it helps reduce maintenance time while ensuring long-term reliability in condition monitoring systems.
Q1: What is the main use of 330104-00-22-10-02-00?
A1: It is used for vibration and shaft position monitoring in rotating industrial equipment.
Q2: Is it compatible with other 3300 XL components?
A2: Yes, it is fully interchangeable with other Bently Nevada 3300 XL probes and systems.
Q3: Can it operate in harsh environments?
A3: Yes, it features armored cable and stainless-steel construction for industrial conditions.
Q4: What type of signal does it provide?
A4: It delivers a voltage output proportional to the distance between probe tip and target surface.
Q5: Is special installation tool required?
A5: No, the ClickLoc connector system allows tool-free installation and removal.
| Number | Description |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System manual |
| 175751 | 3300 XL stainless steel housing, 12”×12”×6”, supports up to 8 DIN-mount or 6 panel-mount Proximitor sensors |
| 176467 | 3300 XL stainless steel housing, 12”×8”×6”, supports up to 4 Proximitor sensors |
| 330181 | 3300 XL stainless steel housing, 13”×9.5”×7”, supports hazardous area certified installations |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire |
| 138492-01 | Replacement panel-mount mounting pad |
| 138493-01 | Replacement DIN-mount mounting pad |
| 148722-01 | 3300 XL test plug with 3-pin adapter and banana plug leads for sensor testing |
| 04310310 | Panel-mount screw for 3300 XL Proximitor Sensor, 6-32 UNC thread |
| 03200006 | Silicone self-fusing tape for connector insulation and environmental protection |
| 40113-02 | Connector protector kit for 3300 XL probes and extension cables |
| 136536-01 | Connector protector adapter for pre-1998 installation tools and 75Ω ClickLoc connectors |
| 40180-02 | Package of 10 pairs of connector protectors for 3300 XL probes and extension cables |
| 03839410 | 75Ω triaxial male connector protector for extension cable environmental protection |
| 03839420 | 75Ω triaxial female connector protector for probe and Proximitor sensor connection protection |
| 04301007 | 3/8-24 probe lock nut with safety wire holes for secure installation |
