Product Name: PACSystems RX7i 17-Slot Front Mount Rack
Brand Name: GE Fanuc
Model Number: IC698CHS117
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
Phone/Whatsapp |
|
Jim Pei |
| Product Name | GE Fanuc IC698CHS117 PACSystems RX7i 17-Slot Front Mount Rack |
| Manufacturer | GE Fanuc |
| Product Type | PACSystems RX7i 17-Slot Front Mount Rack |
| Part Number | IC698CHS117 |
| Weight | 6.16kg |
| Estimated shipping dimensions | 48.3x28.3x19.8cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Mounting Type | Front Mount / Panel Mount |
| Supported Systems / Modules | RX7i CPU and I/O configurations; Series 90-70 I/O; VME modules |
| Number of Slots | Slots 1–17: 17 module slots |
| Slot Width | 0.8 in. (20.3 mm), Slots 1–17 |
| Power Supply Slot | Slot 0; 2.4 in. (61.0 mm) wide |
| CPU Location | Slot 1 |
| Module Capacity | Up to 15 single-width modules or 8 double-width modules, or a combination of both |
| Backplane / VME Support | VME64 |
| Backplane Feature | J2 connectors supporting high-speed VME transfers up to 64 data bits per cycle |
| I/O References | User configurable with programming/configuration software |
| 100 W Power Supply – +5 V | 20 A |
| 100 W Power Supply – +12 V | 2 A |
| 100 W Power Supply – −12 V | 1 A |
| 350 W Power Supply – +5 V | 60 A |
| 350 W Power Supply – +12 V | 12 A |
| 350 W Power Supply – −12 V | 4 A |
| Enclosure Requirement | Protective enclosure rated IP54 or greater |
| Optional Cooling | Supports rack fan assembly |
| Grounding | #8-32 ground studs; minimum AWG #12 (3.33 mm²) wire to earth ground |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The GE Fanuc IC698CHS117 is a 17-slot front-mount rack designed for PACSystems RX7i control and I/O configurations. It provides 17 module positions plus a dedicated power supply slot, supports RX7i CPUs, Series 90-70 I/O, and compatible VME modules, and incorporates a VME64 backplane with J2 connectors for high-speed data transfers. Designed as the structural and electrical foundation of an RX7i control station, the rack provides flexible module arrangement and expansion for complex automation systems. It is suitable for centralized PLC installations in manufacturing, process control, material handling, power generation, and other industrial applications requiring modular controller and I/O configurations.
1. What is the GE Fanuc IC698CHS117 used for?
The GE Fanuc IC698CHS117 provides the mounting structure and backplane connections for CPU, I/O, power supply, and compatible modules in PACSystems RX7i automation systems.
2. How many slots does the GE Fanuc IC698CHS117 provide?
The GE Fanuc IC698CHS117 provides 17 module slots, numbered 1 through 17, along with a separate Slot 0 for the power supply.
3. Where is the CPU installed in the GE Fanuc IC698CHS117?
The CPU in the GE Fanuc IC698CHS117 is installed in Slot 1.
4. Which modules are compatible with the GE Fanuc IC698CHS117?
The GE Fanuc IC698CHS117 supports RX7i CPU and I/O configurations, compatible Series 90-70 I/O modules, and compatible VME modules.
5. What backplane technology does the GE Fanuc IC698CHS117 use?
The GE Fanuc IC698CHS117 uses a VME64 backplane with J2 connectors supporting high-speed data transfers.
6. How many modules can the GE Fanuc IC698CHS117 accommodate?
The GE Fanuc IC698CHS117 can accommodate up to 15 single-width modules or 8 double-width modules, as well as compatible combinations of both sizes.
7. What mounting method does the GE Fanuc IC698CHS117 use?
The GE Fanuc IC698CHS117 is designed for front-mount or panel-mount installation.
