Product Name: Motion Mate Control Module
Brand Name: General Electric
Model Number: IC693DSM302
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The GE IC693DSM302 Motion Mate Control Module is an industrial motion control component designed for the GE Fanuc Series 90-30 PLC platform. It provides high-precision control for multi-axis motion applications, enabling accurate regulation of position, velocity, and acceleration parameters. Manufactured by General Electric, this module is intended for advanced automation systems requiring synchronized motion control and reliable real-time performance.
The module supports integration into PLC-based systems and is equipped with RS-232 communication, non-volatile program storage, and dual-axis control capability. Its compact design and robust industrial specifications make it suitable for demanding manufacturing and process automation environments.
| Product Name | GE IC693DSM302 Motion Mate Control Module |
| Manufacturer | General Electric |
| Product Type | Motion Mate Control Module |
| Part Number | IC693DSM302 |
| Weight | 0.34kg |
| Estimated shipping dimensions | 3.5x13x13.6cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Programming units resolution (position) | -8,388,608 to 8,388,607 user units per second |
| Programming units resolution (velocity) | 1 to 8,388,607 user units per second |
| Programming units resolution (acceleration) | 1 to 134,217,727 user units per second |
| Backplane current consumption | 450 milliAmps at 5 Volts DC (typical) |
| Operating temperature | 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit) |
| Storage temperature | -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit) |
| Compatible components | Programmable logic controllers |
| Block processing time | Less than 5 milliseconds |
| Number of axis | 2 |
| Serial port | RS-232 |
| Non-volatile storage | 10 programs and 40 subroutines |
High precision motion control: supports wide programming resolution for position, velocity, and acceleration
Compact dual-axis design: enables efficient multi-axis control without additional modules
Fast processing speed: sub-5 ms execution improves system responsiveness
Reliable industrial performance: designed for stable operation in harsh environments
Flexible programming storage: supports multiple programs and subroutines for complex automation logic
Compared with similar modules: offers stronger integration with GE Series 90-30 PLC systems and better real-time responsiveness than basic motion interfaces
The IC693DSM302 provides precise, fast, and reliable motion control in a compact PLC-integrated format, making it suitable for advanced industrial automation compared to standard motion control modules.
The IC693DSM302 is fully compatible with GE Fanuc Series 90-30 PLC systems and is designed to integrate directly into the PLC backplane architecture. It works seamlessly with CPU modules, I/O modules, and other system components within the same platform, ensuring synchronized operation between motion control and overall automation logic.
It supports interoperability through its RS-232 serial communication interface, enabling connection with external controllers, programming devices, and industrial equipment. The module is also capable of integrating into larger GE automation systems, allowing coordinated motion control across multi-module PLC configurations and ensuring smooth data exchange within industrial control networks.
