Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330103-00-05-05-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330103-00-05-05-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Specification |
|---|---|
| Model Number | 330103-00-05-05-02-00 |
| Product Type | 3300 XL 8 mm Proximity Probe |
| Thread Type | M10 x 1 Metric Thread |
| Unthreaded Length | 0 mm |
| Overall Case Length | 50 mm |
| Total Cable Length | 0.5 meter |
| Cable Type | Standard Cable |
| Connector Option | Miniature Coaxial ClickLoc Connector |
| Probe Tip Diameter | 8 mm |
| Case Material | AISI 303 / 304 Stainless Steel |
| Tip Material | PPS (Polyphenylene Sulfide) |
| Operating Temperature | -52°C to +177°C |
| Weight | Approx. 0.32 kg/m (probe assembly reference) |
| Compatibility | Works with 3300 XL Extension Cable & Proximitor Sensor |
330103-00-05-05-02-00 is a high-performance Bently Nevada 3300 XL 8 mm proximity probe engineered for precise shaft vibration and position monitoring in rotating machinery. Built with an M10 x 1 threaded stainless-steel case, this model delivers stable eddy-current sensing for turbines, compressors, pumps, and motors operating in demanding industrial environments.
Designed as part of the 3300 XL transducer family, 330103-00-05-05-02-00 offers excellent interchangeability with compatible extension cables and Proximitor sensors. Its rugged PPS probe tip, corrosion-resistant housing, and ClickLoc connector design support fast installation and dependable long-term operation with minimal maintenance.
Compared with older probe generations such as 330103, 330104, and related 3300 XL models, this probe provides stronger mechanical durability, consistent signal output, and reliable performance under vibration, oil mist, and temperature variation. It is widely selected for predictive maintenance and machine protection systems worldwide.
Q1: What is 330103-00-05-05-02-00 used for?
A1: It is used for non-contact vibration and shaft position monitoring on rotating machinery.
Q2: Is this probe compatible with 3300 XL systems?
A2: Yes, it is designed for use with compatible 3300 XL extension cables and Proximitor sensors.
Q3: What thread type does this model use?
A3: It uses an M10 x 1 metric threaded case.
Q4: Can it work in high-temperature environments?
A4: Yes, the standard probe supports temperatures up to +177°C.
Q5: Which industries commonly use this probe?
A5: Power generation, oil & gas, steel, marine, chemical, and manufacturing industries commonly use it.
| Number | Describe |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual |
| 175751 | 3300 XL Multi-Purpose Stainless Steel Housing, 12”x12”x6”, holds up to 8 Proximitor Sensors (DIN-mount) or 6 sensors (panel-mount), available with ATEX Zone 0 and Zone 1 certifications |
| 176467 | 3300 XL Multi-Purpose Stainless Steel Housing, 12”x8”x6”, holds up to 4 Proximitor Sensors in DIN-mount or panel-mount configurations, available with ATEX Zone 0 and Zone 1 certifications |
| 330181 | 3300 XL Multi-Purpose Stainless Steel Housing, 13”x9.5”x7”, holds up to 8 Proximitor Sensors (DIN-mount) or 6 sensors (panel-mount), for hazardous area approvals, available with ATEX Zone 0/1 and North American Division 1/2 certifications |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3 conductor twisted shielded cable with drain wire, specify length in feet |
| 138492-01 | Replacement panel-mount mounting pad |
| 138493-01 | Replacement DIN-mount mounting pad |
| 148722-01 | 3300 XL test plug with 3 test pins, 3 color-coded 1-meter wires, banana plugs, used for Proximitor sensor performance testing without removing field wiring |
| 04310310 | 3300 XL Proximitor Sensor panel-mount screw, one 6-32 UNC thread forming mounting screw, four required per sensor |
| 03200006 | Silicone self-fusing tape, 9.1-meter (10-yard) roll, provides connector protection, electrical isolation, and environmental sealing |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, includes connector protectors and installation tools |
| 136536-01 | Connector protector adapter for pre-1998 installation tools with 75Ω ClickLoc connectors |
| 40180-02 | Connector protectors, package of 10 pairs for 3300 XL 8 mm probes and extension cables |
| 03839410 | 75Ω triaxial male connector protector for extension cable, provides environmental protection |
| 03839420 | 75Ω triaxial female connector protector for probe lead or Proximitor sensor connection, provides environmental protection |
| 04301007 | 3/8-24 probe lock nut with safety wire holes, single lock nut with 2 drilled holes |
| 04301008 | M10 x 1 probe lock nut with safety wire holes, single lock nut with 2 drilled holes |
| 330153-01 | 3300 XL connector kit for probes and extension cables, includes male/female ClickLoc connectors, sleeves, slit FEP tubing, and silicone tape |
| 330153-09 | 3300 XL ETR Connector Kit for ETR probes and extension cables, includes high-temperature components and silicone tape |
| 163356 | Connector Crimp Tool Kit with multiconnector inserts, installation instructions, compatible with 330153 kits, supplied with carrying case |
