Product Name: DISCRETE OUTPUT MODULE
Brand Name: General Electric
Model Number: IC697MDL740
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | GE IC697MDL740 DISCRETE OUTPUT MODULE |
| Manufacturer | General Electric |
| Product Type | DISCRETE OUTPUT MODULE |
| Part Number | IC697MDL740 |
| Weight | 0.88kg |
| Estimated shipping dimensions | 4x22x29.1cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Output current | 2 Amps per point, 4 Amps per group |
| Output voltage range | 20 to 60 Volts DC |
| Inrush current | 20 Amps (maximum) for 20 milliseconds |
| Response time-off | 2 milliseconds (maximum) |
| Output voltage drop | 0.8 Volts/0.4 Ohms (maximum) |
| Series | Series 90-70 |
| Required current | 0.15 Amps |
| Number of outputs | 16 |
| Isolation voltage | 1500 Volts |
| Rated voltage | 24 to 48 Volts DC |
| GE Fanuc Series 90-70 | High Inrush Output Module |
| Series 90-70 PLC Module | Isolated Output Module |
| GE PLC Output Module | 16-Point Output Module |
| Discrete Output Module | Industrial Control Module |
| Digital Output Module | Factory Automation Equipment |
| 24VDC Output Module | GE Automation Parts |
| 48VDC Output Module | Industrial PLC Components |
| Industrial Automation Module | Contactors Control Module |
| PLC I/O Module | DC Output Interface Module |
| PLC Output Card | Industrial Control System Solutions |
The GE IC697MDL740 is a high-performance discrete output module designed for the Series 90-70 PLC platform. Featuring 16 output points arranged into four isolated groups of four outputs each, the module delivers reliable switching performance for industrial automation and process control applications. Its isolated group architecture enables independent control of multiple circuits, improving system flexibility and operational efficiency.
Engineered for demanding industrial environments, the IC697MDL740 supports a rated voltage of 24 to 48 VDC and an operating output voltage range of 20 to 60 VDC. With a high inrush current capability of up to 20 Amps for 20 milliseconds, the module is ideal for controlling relays, solenoids, contactors, motor starters, and incandescent lighting loads. Built-in fuse protection and 1500V isolation provide enhanced safety and long-term reliability.
16-Point Digital Output Control
Provides 16 discrete output channels for controlling industrial field devices such as relays, contactors, solenoids, and indicator lamps.
Four Isolated Output Groups
Organizes outputs into four electrically isolated groups of four points each, allowing independent circuit operation and simplified system design.
High Current Output Capability
Supports up to 2 Amps per output point and 4 Amps per output group for demanding industrial control applications.
High Inrush Current Handling
Delivers up to 20 Amps inrush current for 20 milliseconds, enabling reliable startup of inductive and incandescent loads.
Individual Group Fuse Protection
Each output group is protected by a dedicated 10A fuse, reducing the risk of system damage and minimizing maintenance downtime.
Fast Switching Response
Provides a maximum OFF response time of 2 milliseconds for precise and responsive control performance.
Wide Voltage Range Operation
Supports output voltages from 20 to 60 VDC, making the module suitable for various industrial DC power systems.
Compared with other standard 16-point DC output modules, the GE IC697MDL740 offers higher inrush current capability, superior output isolation, and enhanced protection features. Its ability to handle demanding inductive loads, combined with four isolated output groups and individual fuse protection, makes it a more reliable and flexible solution for industrial automation systems.
Q1: What is the GE IC697MDL740 used for?
The GE IC697MDL740 is used to provide discrete DC output control for industrial devices such as relays, contactors, solenoid valves, indicator lamps, and other field equipment.
Q2: How many output points does the GE IC697MDL740 provide?
The GE IC697MDL740 provides 16 discrete output points organized into four isolated groups of four outputs each.
Q3: What voltage range does the GE IC697MDL740 support?
The GE IC697MDL740 supports an output voltage range of 20 to 60 VDC and is commonly used in 24VDC and 48VDC control systems.
Q4: What is the maximum output current of the GE IC697MDL740?
The GE IC697MDL740 supports up to 2 Amps per output point and 4 Amps per output group.
Q5: Can the GE IC697MDL740 drive inductive loads?
Yes. The GE IC697MDL740 is specifically designed to handle inductive loads and supports up to 20 Amps of inrush current for 20 milliseconds.
