| Product Name | GE IC697MDL940 OUTPUT MODULE |
| Manufacturer | General Electric |
| Product Type | OUTPUT MODULE |
| Part Number | IC697MDL940 |
| Weight | 0.66kg |
| Estimated shipping dimensions | 4x22x29.1cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| No. of channels per group | Four (4) per group |
| Output configuration | Eight (8) Form C relay outputs; Eight (8) Form A outputs |
| Frequency | 47 to 63 Hertz (for AC voltage only) |
| Load current (maximum) | 16 Amps per module, 4 Amps per group |
| Output leakage (maximum) | 1 milliAmp at 120 Volts AC |
| Switching Frequency | 20 cycles/minute (inductive load) |
| Rated voltage | 120/240 Volts AC or 5/24/125 Volts DC |
| Power Rating | 480 VA or 60 Watts |
| Points | 16 Point |
| 16 Point Output Module | AC/DC Output Module |
| Form C Relay Output | 120/240 VAC Output Module |
| Form A Output Module | 24 VDC Output Module |
| GE Industrial Automation | 125 VDC Output Module |
| IC697MDL940 Relay Card | GE Series 90-70 Accessories |
| PLC Output Interface | Machine Control Output Module |
| Industrial Control Output Module | Industrial Switching Module |
| GE I/O Module | Control Cabinet Output Device |
| High Current Relay Module | Rugged PLC Output Card |
| Factory Automation Hardware | Relay Switching Interface Module |
The GE IC697MDL940 is a 16-point relay output module designed for the GE Series 90-70 PLC platform. It provides flexible switching control for a wide range of industrial loads, including relays, contactors, and indicator lamps, supporting both AC and DC applications.
Built with rugged industrial design, the IC697MDL940 offers reliable output performance with Form A and Form C relay configurations. It is widely used in factory automation, process control, and machine control systems where dependable load switching is required.
Relay Output Switching
The GE IC697MDL940 provides 16 relay output points to control industrial devices such as contactors, relays, lamps, and alarms.
AC/DC Load Control
Supports switching of both AC and DC loads, including 120/240 VAC and 5/24/125 VDC applications.
Form A and Form C Output Structure
Includes 8 Form C and 8 Form A relay outputs for flexible control configurations.
High Current Output Capability
Delivers up to 2 A per output point and supports up to 16 A per module for industrial load handling.
Built-in Protection Features
Each output point is equipped with RC snubber and fuse protection to improve safety and extend module life.
Status Indication
LED indicators display ON/OFF status for each channel, enabling quick diagnostics and monitoring.
Easy Field Wiring
Uses a removable terminal block for simplified installation, wiring, and maintenance.
PLC System Integration
Integrates directly with GE Series 90-70 PLC systems for reliable automation control.
Compared with similar relay output modules, the GE IC697MDL940 offers higher load flexibility, stronger protection features, and easier maintenance, making it suitable for demanding industrial automation applications.
Flexible Load Compatibility: Supports AC and DC switching including 120/240 VAC and 5/24/125 VDC applications.
High Switching Capacity: Delivers up to 2 A per point and 16 A per module for robust load control.
Strong Built-in Protection: Each output includes RC snubber and fuse protection for improved safety and durability.
Clear Status Indication: LED indicators provide real-time ON/OFF status for easy diagnostics.
Easy Maintenance Design: Removable field wiring terminal simplifies installation and replacement.
Rugged Industrial Construction: Designed for reliable operation in harsh industrial environments.
Flexible System Integration: Fully compatible with GE Series 90-70 PLC systems for seamless deployment.
How many output points does GE IC697MDL940 have?
The GE IC697MDL940 provides 16 relay output points.
What types of outputs are available in GE IC697MDL940?
The GE IC697MDL940 includes 8 Form C and 8 Form A relay outputs.
What voltage can GE IC697MDL940 switch?
The GE IC697MDL940 supports switching of 120/240 VAC and 5/24/125 VDC loads.
What is the output current capacity of GE IC697MDL940?
The GE IC697MDL940 supports up to 2 A per point and 16 A per module.
Does GE IC697MDL940 include protection features?
Yes, the GE IC697MDL940 includes RC snubber and fuse protection on each output point.
Does GE IC697MDL940 require external power supply?
No, the GE IC697MDL940 does not require user external power; relay operation is powered internally by the module.
How is GE IC697MDL940 maintained or replaced?
The GE IC697MDL940 features a removable field wiring terminal and keyed mechanical design for easy replacement and maintenance.
