GE IC698RMX016 COMMUNICATION MODULE

Product Name: COMMUNICATION MODULE

Brand Name: General Electric

Model Number: IC698RMX016

Place of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

Overview
Commercial Terms
Product Parameters
Introduction
Functions
Features
Advantage
FAQ
Recommended Products

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Product Parameters

Product Name	GE IC698RMX016 COMMUNICATION MODULE
Manufacturer	General Electric
Product Type	COMMUNICATION MODULE
Part Number	IC698RMX016
Weight	0.3kg
Estimated shipping dimensions	2x18x29.1cm
Place of shipment	Xiamen, China
Country of origin	USA
User memory	16MB SDRAM
Operating voltage	+5VDC
Current requirements	1.8A
Insertion Loss	0.35 dB
Return Loss	-30dB
Temperature Range	-20°C to +85°C

Introduction

The GE IC698RMX016 Communication Module is a control memory xchange (CMX) module designed for PACSystems RX7i PLC platforms. It enables deterministic, real-time data sharing between multiple controllers and computing devices over a fiber-optic network. Using reflective memory technology, the IC698RMX016 ensures that any data written to one node is instantly replicated across all connected nodes, supporting highly synchronized control in distributed automation systems.

Designed for mission-critical industrial applications, the IC698RMX016 supports a high-speed 2.12 Gbaud fiber-optic network and is compatible with the VMIC 5565 reflective memory family. With support for up to 256 nodes and multimode fiber connections up to 300 meters, the module provides scalable, low-latency communication for complex control architectures. Its robust design, VMEbus interrupt capability, and configurable packet handling make it ideal for high-performance synchronization, simulation, and real-time control environments.

Functions

Enables real-time deterministic data sharing across multiple PLCs and computing systems.
Synchronizes memory updates instantly across all nodes in a reflective memory network.
Supports high-speed fiber-optic communication using 2.12 Gbaud transmission.
Facilitates distributed control system coordination and data exchange.
Provides VMEbus interrupt output for system-level event handling.
Generates four general-purpose network interrupts with 32-bit data support.
Manages dynamic data packet transmission from 4 to 64 bytes.
Supports up to 256 interconnected network nodes.
Ensures seamless communication between PACSystems RX7i and VMIC-compatible devices.
Enables high-speed synchronization for simulation, monitoring, and control applications.
Maintains deterministic data consistency across all connected systems.

Features

16 Mbytes reflective memory with parity protection
16 MB SDRAM user memory capacity
High-speed 2.12 Gbaud fiber-optic network communication
Supports multimode fiber connections up to 300 m (984 ft)
Compatible with VMIC 5565 family reflective memory devices
Supports up to 256 network nodes
Dynamic packet sizes from 4 to 64 bytes
Software-configurable node parameters
Four general-purpose network interrupts (32-bit data each)
Programmable VMEbus interrupt output
Low insertion loss of 0.35 dB
Return loss of -30 dB for signal integrity
Operating voltage: +5 VDC
Current requirement: 1.8 A
Operating temperature range: -20°C to +85°C
Single-slot PACSystems RX7i rack compatibility
Fiber-optic daisy-chain network topology support
Supports deterministic high-speed data synchronization

Advantage

Compared with conventional industrial communication modules, the IC698RMX016 provides significantly faster deterministic data exchange, higher synchronization accuracy, and scalable multi-node network architecture.

Enables real-time memory mirroring across all connected nodes with zero software latency.
Supports ultra-high-speed 2.12 Gbaud fiber-optic communication.
Allows up to 256-node network expansion for large distributed systems.
Ensures deterministic data consistency across all controllers.
Eliminates polling delays through automatic hardware-based synchronization.
Provides flexible integration with VMIC 5565-compatible systems.
Supports long-distance fiber connections up to 300 meters.
Reduces system complexity by eliminating traditional message-based communication.
Improves system reliability through parity-protected reflective memory.
Enables high-performance applications such as simulation, testing, and synchronized control.

FAQ

Q: How does the IC698RMX016 synchronize data across systems?
A: The IC698RMX016 uses reflective memory technology, meaning that any data written to one node is automatically and instantly replicated to all other nodes in the network.

Q: How many nodes can the IC698RMX016 support in a network?
A: The IC698RMX016 supports up to 256 nodes in a single reflective memory network.

Q: What type of communication does the IC698RMX016 use?
A: The IC698RMX016 uses a high-speed 2.12 Gbaud fiber-optic communication network compatible with VMIC 5565 family devices.

Q: What is the memory capacity of the IC698RMX016?
A: The IC698RMX016 provides 16 Mbytes of reflective memory with parity protection and 16 MB SDRAM user memory.

Q: What is the operating temperature range of the IC698RMX016?
A: The IC698RMX016 operates within a temperature range of -20°C to +85°C, making it suitable for harsh industrial environments.

Q: Can the IC698RMX016 be configured through software?
A: Yes, the IC698RMX016 supports software configuration of all node parameters for flexible system setup and management.

Q: What makes the IC698RMX016 suitable for distributed control systems?
A: The IC698RMX016 provides ultra-low latency, deterministic data synchronization, and support for up to 256 nodes, making it ideal for high-performance distributed automation and real-time control applications.
