GE Multitin 750/760 Feeder Management Relay 750-P5-G5-HI-A20-R In stock

GE Multitin 750/760 Feeder Management Relay 750-P5-G5-HI-A20-R In stock

Product Name: Feeder Management Relay

Brand Name: GE

Model Number:750-P5-G5-HI-A20-R

Country of Origin:USA

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

760 feeder management relay 750 p5 g5 hi a20 r in stock-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Recommended Products

Overview

Brand Name:	General Electric
Model Number:	750-P5-G5-HI-A20-R
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	Delivery time in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Model	750-P5-G5-HI-A20-R
Type	Feeder Management Relay
Phase Current Inputs	5 A (P5)
Zero-Sequence Current Input	5 A (G5)
Sensitive Ground Input	5 A (S5)
Analog Outputs	8 channels, 4–20 mA (A20)
Control Power	HI: 88–300 V DC; 70–265 V AC at 48–62 Hz
Communication Ports	1x Ethernet 10 Mbps, 1x RS232, 2x RS422/RS485
Protocols	Modbus RTU, DNP 3.0 Level 2, TCP/IP
Display	Enhanced LCD with backlight
Dimensions	178 × 229 × 178 mm (7.0 × 9.0 × 7.0 in)
Weight	Approx. 4.8 kg (10.6 lb)
Operating Temperature	-20°C to 60°C (-4°F to 140°F)

Description

The 750-P5-G5-HI-A20-R is an enhanced feeder management relay from GE Multilin's 750 series, designed for comprehensive protection and control of electrical distribution feeders. This 750-P5-G5-HI-A20-R model features 5 A phase, zero-sequence, and sensitive ground current inputs, high-range control power, and eight 4–20 mA analog outputs. The 750-P5-G5-HI-A20-R incorporates a dual-processor architecture with a large backlit display and improved menu navigation. It integrates protection, metering, monitoring, and communication capabilities into a single drawout package for demanding industrial and utility applications.

Applications

Distribution feeder protection and management
Transformer and bus backup protection
Industrial power distribution systems
Utility substation feeder monitoring
Manufacturing and energy facilities
Mining and commercial electrical networks

Features

Dual-processor architecture (32-bit and 16-bit) for precise data processing
Enhanced backlit LCD with intuitive menu navigation
8 configurable 4–20 mA analog outputs
Drawout case design for reduced maintenance time
Comprehensive overcurrent, ground fault, and thermal protection
Oscillography with movable cursors and zoom functionality
Flash memory for field firmware upgrades

Functions

The relay provides primary protection for distribution feeders including overcurrent, ground fault, and thermal overload detection. It performs real-time monitoring of voltage, current, and frequency parameters. The device logs events and faults for post-incident analysis, supports remote communication via Modbus RTU, DNP3, and TCP/IP protocols, and enables oscillography for waveform capture and analysis.

FAQ

Q1: What current inputs does the 750-P5-G5-HI-A20-R support?
A1: The relay supports 5 A phase current inputs (P5), 5 A zero-sequence current inputs (G5), and 5 A sensitive ground current inputs (S5).

Q2: What is the control power range for the 750-P5-G5-HI-A20-R?
A2: It accepts 88–300 V DC or 70–265 V AC at 48–62 Hz.

Q3: How many analog outputs does the 750-P5-G5-HI-A20-R provide?
A3: The relay provides eight 4–20 mA analog outputs.

Q4: What communication protocols does the 750-P5-G5-HI-A20-R support?
A4: It supports Modbus RTU, DNP 3.0 Level 2, and TCP/IP protocols.

Q5: What is the operating temperature range of the 750-P5-G5-HI-A20-R?
A5: The relay operates from -20°C to 60°C (-4°F to 140°F).

Enquiry Now: [email protected]
