Product Name: Digital Input Module
Brand Name: ABB
Model Number: DI814 3BUR001454R1
Place of Origin: Sweden
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Tag
| ABB System 800xA | Industrial Signal Interface |
| AC 800M I/O Module | Group-Isolated Input Module |
| Industrial Automation I/O | High Noise Immunity I/O |
| PLC Input Card | Process Automation Module |
| DCS Input Module | Distributed Control System (DCS) |
| 24V DC Digital Input | Industrial Control System Component |
| 16-Channel Input Module | Electrical Isolation Module |
| Field Signal Acquisition | Field Device Interface |
| Control System Hardware | ABB I/O System Hardware |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | ABB DI814 3BUR001454R1 Digital Input Module |
| Manufacturer | ABB |
| Product Type | Digital Input Module |
| Part Number | DI814 3BUR001454R1 |
| Estimated shipping dimensions: | 4.5x10.5x12cm |
| Weight: | 0.16 kg |
| Place of shipment | Xiamen, China |
| Country of origin | Sweden |
| Signal specification | 24 V d.c. |
| Number of channels | 16 |
| Input impedance | 3.5 kO |
| Isolation | Groupwise isolated from ground, 2 groups with 8 channels |
| Rated insulation voltage | 50 V |
| Dielectric test voltage | 500 V a.c. |
| Power dissipation | Typ. 1.8 W |
The ABB DI814 3BUR001454R1 Digital Input Module is an industrial-grade 16-channel digital input module designed by ABB for use in automation and control systems. It is used to collect 24 V DC digital signals from field devices such as switches, sensors, and contactors, and transmit them to PLC or DCS controllers for processing.
The module is commonly used in ABB System 800xA and AC 800M architectures, providing reliable signal acquisition with high electrical isolation and stable performance. Its compact design and low power dissipation make it suitable for dense I/O configurations in industrial environments.
Signal Configuration
The ABB DI814 3BUR001454R1 Digital Input Module is configured to receive 24 V DC digital signals. Each input channel must be correctly mapped in the PLC or DCS system to ensure accurate signal interpretation from field devices.
Channel Group Configuration
The module is divided into two isolated groups of 8 channels. Proper group assignment improves noise immunity and ensures electrical separation between different field circuits.
System Integration
The DI814 integrates into ABB System 800xA and AC 800M I/O systems. It communicates input status to the controller for real-time monitoring and control logic execution.
Installation Setup
The module should be installed in an I/O rack with correct grounding and wiring practices. Proper installation ensures signal stability and minimizes electromagnetic interference.
Diagnostics & Maintenance
Channel status can be monitored through system diagnostics. Regular inspection of wiring and field connections helps maintain reliable signal acquisition and reduces downtime risk.
Programming Requirements
No internal programming is required for the module itself. Configuration is performed in the control system (PLC/DCS), where input channels are assigned and used within control logic.
