Product Name:3300 XL 8 mm Proximity Probes
Brand Name:BENTLY NEVADA
Model Number:330101-10-27-05-02-05
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330101-10-27-05-02-05 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Specification |
|---|---|
| Model | 330101-10-27-05-02-05 |
| Probe Type | 3300 XL 8 mm proximity probe |
| Output Sensitivity | 7.87 V/mm (200 mV/mil) |
| Linear Range | 0.25 mm to 2.3 mm |
| Cable Type | 75Ω triaxial FEP insulated |
| Connector | Gold-plated ClickLoc connector |
| Operating Temp | -52°C to +177°C |
| Thread Type | 3/8-24 UNF |
| Total Length Options | 0.5 m to 9 m |
| Weight | ~323 g/m (probe body) |
| System Compatibility | 3300 XL Proximitor Sensor |
The330101-10-27-05-02-053300 XL 8 mm proximity probe is engineered for high-precision vibration and position monitoring in industrial machinery. As part of the Bently Nevada 3300 XL series, it integrates with3300 XL extension cablesand3300 XL Proximitor Sensorsto deliver stable, non-contact measurement performance in demanding environments.
Built on the3300 XL 8 mm platform, the330101probe supports fluid-film bearing machines, providing accurate radial vibration, axial position, and Keyphasor reference signals. Its robust construction ensures reliable operation under high temperature, electrical noise, and mechanical stress conditions commonly found in turbines, compressors, and rotating equipment systems.
Designed for interchangeability and compliance with API 670 standards, the330101-10-27-05-02-05ensures consistent signal output, easy installation, and long-term stability across critical monitoring applications.
Q1: What is the main use of the 330101 probe?
A1: It is used for non-contact vibration and position measurement in rotating machinery systems.
Q2: Is 330101 compatible with all 3300 XL systems?
A2: Yes, it is fully compatible with 3300 XL Proximitor Sensors and extension cables.
Q3: Can it operate in high-temperature environments?
A3: Yes, it supports operating temperatures up to +177°C.
Q4: Does it support Keyphasor applications?
A4: Yes, it is widely used for speed and phase reference measurements.
Q5: Is the connector resistant to loosening?
A5: Yes, the ClickLoc connector ensures secure and vibration-resistant locking
| Number | Description |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual |
| 175751 | 3300 XL multi-purpose stainless steel housing 12"x12"x6", supports up to 8 DIN-mounted or 6 panel-mounted Proximitor sensors, ATEX Zone 0/1 certified |
| 176467 | 3300 XL stainless steel housing 12"x8"x6", supports up to 4 Proximitor sensors in DIN or panel mount configuration, ATEX Zone 0/1 certified |
| 330181 | 3300 XL stainless steel housing 13"x9.5"x7", supports up to 8 DIN or 6 panel-mounted Proximitor sensors, suitable for hazardous area installations, ATEX Zone 0/1 and North American Division 1/2 certified |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, length customizable |
| 138492-01 | Replacement panel-mount mounting pad for 3300 XL system |
| 138493-01 | Replacement DIN-mount mounting pad for 3300 XL system |
| 148722-01 | 3300 XL test plug with 3-pin adapter and banana plugs for sensor performance testing without removing field wiring |
| 04310310 | 6-32 UNC panel-mount screw for Proximitor sensor installation, 4 screws required per sensor |
| 03200006 | Silicone self-fusing tape, 9.1-meter roll, provides insulation and environmental protection for connectors |
| 40113-02 | Connector protector kit for 3300 XL 8 mm probes and extension cables, includes installation tools |
| 136536-01 | Connector protector adapter for compatibility with pre-1998 installation tools and 75Ω ClickLoc connectors |
| 40180-02 | Connector protectors package, includes 10 pairs for probes and extension cables |
| 03839410 | Male 75Ω triaxial connector protector for extension cable, provides environmental sealing |
| 03839420 | Female 75Ω triaxial connector protector for probe lead and Proximitor sensor connections, ensures environmental protection |
